Quick Details
-
Weight (KG):
-
140000
-
Brand Name:
-
Xinfu
-
Place of Origin:
-
Shandong, China
-
Die Size(mm):
-
2000 - 2200 mm
-
Model Number:
-
3TGM4500
-
Year:
-
2023
-
Voltage:
-
220/380/440V/50/60Hz
-
Dimension(L*W*H):
-
20x10x26.5 meter
-
Processing Type:
-
Extrusion blowing Machine
-
Product:
-
HDPE geomembrane
-
Usage:
-
Waterproof
-
Machine color:
-
Standard or customized.
-
Automatic Grade:
-
Semi-automatic
-
Die diameter:
-
2000mm
-
Keywords:
-
3-Layer Geomembrane Machine geomembrane 8 meter
-
Extruder:
-
180x3
-
main motor:
-
280KWx3
Quick Details
-
Output (kg/h):
-
1200 - 1500
-
Number of Layers:
-
Three-layer
-
Screw diameter (mm):
-
180
-
Weight (KG):
-
140000
-
Brand Name:
-
Xinfu
-
Place of Origin:
-
Shandong, China
-
Die Size(mm):
-
2000 - 2200 mm
-
Model Number:
-
3TGM4500
-
Year:
-
2023
-
Voltage:
-
220/380/440V/50/60Hz
-
Dimension(L*W*H):
-
20x10x26.5 meter
-
Processing Type:
-
Extrusion blowing Machine
-
Product:
-
HDPE geomembrane
-
Usage:
-
Waterproof
-
Machine color:
-
Standard or customized.
-
Automatic Grade:
-
Semi-automatic
-
Die diameter:
-
2000mm
-
Keywords:
-
3-Layer Geomembrane Machine geomembrane 8 meter
-
Extruder:
-
180x3
-
main motor:
-
280KWx3
|
Model |
3TGM3500 |
3TGM4000 |
3TGM4500 |
3TGM5500 |
|
Geomembrane width |
6 meter |
7 meter |
8 meter |
10 meter |
|
Geomembrane thickness |
0.3-2mm |
|||
|
Raw material |
HDPE LDPE LLDPE |
|||
|
Max. Output |
1000 Kg/H |
1600 Kg/H |
1800 Kg/H |
1900 Kg/H |
|
Extruder |
150*1+135*2 |
180*1+150*2 |
180*3 |
180*2+200*1 |
|
Die diameter |
1600mm |
1800mm |
2000mm |
2200mm |
|
Traction speed |
0-10 m/min. |
|||
|
Total power |
900 KW |
1200 KW |
1400 KW |
1550 KW |
|
Dimension |
18*8*21 m |
19*9*24 m |
20*10*26.5 m |
22*11.5*28.5 m |
