Quick Details
-
Model Number:
-
Custom
-
Brand Name:
-
SMM
-
Treatment of tooth:
-
Ground/Milled
-
Surface treatment:
-
Zinc Plating/Black oxide
-
Accuracy Grade:
-
Din 5-10
-
After Warranty Service:
-
Online Video Support
Quick Details
-
Weight (KG):
-
1.7
-
Marketing Type:
-
New Product 2023
-
Place of Origin:
-
Shanghai, China
-
Model Number:
-
Custom
-
Brand Name:
-
SMM
-
Treatment of tooth:
-
Ground/Milled
-
Surface treatment:
-
Zinc Plating/Black oxide
-
Accuracy Grade:
-
Din 5-10
-
After Warranty Service:
-
Online Video Support
Products Description
|
Specification
|
|
|
|
Precision grade
|
ISO grade 6
|
|
|
Pressure angle
|
20°
|
|
|
Material
|
SCM415, 15CrMo, 9310,8620
|
|
|
Heat treatment
|
Tooth are carburized
|
|
|
Tooth hardness
|
55~60 HRC
|
|
|
Module
|
No. of teeth
|
Total length (A)
|
Face width (B)
|
Bending strength
|
Surface durability
|
Height (C)
|
Height to pitch line (D)
|
|
1.5
|
106
|
499.51
|
15
|
5070
|
4620
|
20
|
18.5
|
|
2
|
80
|
502.65
|
20
|
9010
|
8240
|
25
|
23
|
|
2.5
|
64
|
502.65
|
25
|
14100
|
12900
|
30
|
27.5
|
|
3
|
53
|
499.51
|
30
|
20300
|
18600
|
35
|
32
|
Thank you for reaching out to us for your custom gear requirements. Our Engineering team will review your request and will be in contact within 24 hours. - SMM TEAM | sales(@)shsmm.com
