Quick Details
-
Model Number:
-
YG60
-
Model:
-
YG60 Gloss Meter
-
color:
-
White
-
Angles:
-
20°/ 60° /85°
-
size:
-
160*52*84mm
-
weight:
-
0.35g
-
Language:
-
Chinese/English
-
Interface:
-
USB & Bluetooth 2.1 version
-
Warranty:
-
one year
Quick Details
-
Power:
-
Electronic
-
Place of Origin:
-
China
-
Brand Name:
-
HiYi
-
Model Number:
-
YG60
-
Model:
-
YG60 Gloss Meter
-
color:
-
White
-
Angles:
-
20°/ 60° /85°
-
size:
-
160*52*84mm
-
weight:
-
0.35g
-
Language:
-
Chinese/English
-
Interface:
-
USB & Bluetooth 2.1 version
-
Warranty:
-
one year
overview
YG268 Gloss Meter
Multi-angle
20°/60°/85°
It has four measurement modes: basic mode, quality control mode, statistical mode and continuous mode.
It's also a variety of measurement angles, freely switch and with auto-calibration and high-end QC software, it can meet the first grade requirements of JJG696.
Product Feature
Meet a number of industry standards
●Meet the first grade requirements of JJG696
●Comply to ISO2813,ASTM523, GB/T9754
●Meet the first grade requirements of JJG696
●Comply to ISO2813,ASTM523, GB/T9754
Base Mode
After the measurement, the green light will be off and the result will be displayed.
Quality Control Mode
Statistical Mode
In the statistical mode, it carries out multiple average measurements, basic statistics on the data of multiple measurements, and can be compared with the standard samples.
Continuous Mode
number of times.
Multi-angle, to meet a variety of material measurement
20°: High gloss paint (cars), plastics, varnish, sheet, paper and metal .
20°: High gloss paint (cars), plastics, varnish, sheet, paper and metal .
60°: Universal for paints, printing ink, varnish, metal, anodized aluminum, plastics and ceramics.
85°: Matt paint and surfaceMatt paint and surfaces in aviation, military, furniture and automobile interiors Technical Parameters.
85°: Matt paint and surfaceMatt paint and surfaces in aviation, military, furniture and automobile interiors Technical Parameters.
Powerful hardware and software support
● Elegant Design combined with aesthetics and ergonomics
● With auto-calibration function
● Large storage to save over 35000 data
● With PC software for quality report, more extend functions
● Elegant Design combined with aesthetics and ergonomics
● With auto-calibration function
● Large storage to save over 35000 data
● With PC software for quality report, more extend functions
Product Paramenters
|
YG Series Specification Parameter
|
|
|
|
|||
|
Model
|
YG268 Tri-angle
|
YG60 60° Accurate
|
YG60°S Economic
|
|||
|
Measuring Angle
|
20°/60°/85°
|
60°
|
60°
|
|||
|
Measuring Area(mm)
|
20°: 9*1060°: 9*15
85°: 5*38
|
60°: 9*15
|
60°: 9*15
|
|||
|
Measuring Range
|
20°: 0~2000 GU
60°: 0~1000 GU
85°: 0~160 GU
|
60°: 0~1000 GU
|
60°: 0~200 GU
|
|||
|
Division Value
|
0.1 GU
|
0.1 GU
|
1 GU
|
|||
|
Measuring Time
|
0.5S
|
0.5S
|
0.5S
|
|||
|
Repeatalibity
|
0~100 GU: ±0.2 GU
100~2000 GU: ±0.2 GU
|
0~100 GU: ±0.2 GU
100~1000 GU: ±0.2 GU
|
0~100 GU: ±0.5 GU
100~200 GU: ±0.5 GU
|
|||
|
Accurate
|
Conform with JJG696 first grade requirements of gloss meter
|
|
|
|||
|
Auto Power-off Time
|
within 30s~120s
|
|
30s
|
|||
|
Long-time Calibration
|
Automatically check and made the calibration
|
|
|
|||
|
Language
|
Chinese and English
|
|
|
|||
|
Storage
|
35000Basic mode
Statistic mode : 1500
Continuous mode : 10000
QC mode: 10000 |
|
--
|
|||
|
Display
|
2.3 inch white and black screen
|
|
|
|||
|
Size
|
160*52*84mm
|
|
|
|||
|
Weight
|
About 300g
|
|
|
|||
|
Power Supply
|
1pc dry-cell battery(can measure 10000 times) or use USB Charge
|
|
|
|||
|
Interface
|
USB & Bluetooth 2.1 version
|
USB
|
USB
|
|||
|
PC Software
|
GQC6 QC software can printing testing report and with more extended functions
|
|
---
|
|||
|
OperationTemperature
|
0-40℃（32-104° F）
|
|
|
|||
|
Storage Temperature
|
-20-50℃（-4-122° F）
|
|
|
|||
|
Humidity
|
< 85% RH, without condensation
|
|
|
|||
|
Standard Accessories
|
USB cable, user manual, calibration plate, QC software
|
|
User manual, Calibration plat
|
|||
|
Optional Accessories
|
Miniature printer
|
|
|
|||
Application Scenes
Gloss meter can test material with high gloss (0-2000Gu), and universally apply to paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc.
