Quick Details
-
Wheelbase(mm):
-
3200
-
Front wheel tread(mm):
-
960
-
Rear wheel tread(mm):
-
1000
-
Fuel Type:
-
Electric
-
streering system:
-
Self-adjust rack and pinion
-
Brake System:
-
4 wheels disc brake +EM Brake
-
Roof strut:
-
Steel
-
Tire:
-
Off-road tires, 23 x 10-12; Aluminium alloy wheel hub
Quick Details
-
Dimension:
-
4500x1340x1990
-
Overall dimensions(mm):
-
4500x1340x1990
-
Min ground clearance(mm):
-
170
-
Wheelbase(mm):
-
3200
-
Front wheel tread(mm):
-
960
-
Rear wheel tread(mm):
-
1000
-
Fuel Type:
-
Electric
-
streering system:
-
Self-adjust rack and pinion
-
Brake System:
-
4 wheels disc brake +EM Brake
-
Roof strut:
-
Steel
-
Tire:
-
Off-road tires, 23 x 10-12; Aluminium alloy wheel hub
Products Description
|
Key Components
|
|
|
|
|
|
|
|
|||||||
|
Chassis
|
Carbon steel
|
|
|
|
|
standard
|
|
|||||||
|
Battery
|
Maintention-free Battery, 48V150Ah
|
|
|
|
|
standard
|
|
|||||||
|
|
72V/100Ah(with MSDS certificate)
LiFePO4 Lithium Battery (With Certificate) |
|
|
|
|
Optional
|
|
|||||||
|
|
72V/125Ah ternary lithium battery
|
|
|
|
|
Optional
|
|
|||||||
|
Motor
|
Three asynchronous AC motors,5kW
|
|
|
|
|
standard
|
|
|||||||
|
|
Three asynchronous AC motors,7.5KW
|
|
|
|
|
Optional
|
|
|||||||
|
Controller
|
inpower:48V Inpower-3528 72V Inpower-3818
|
|
|
|
|
standard
|
|
|||||||
|
|
brand Curtis-1234SE or SME
|
|
|
|
|
Optional
|
|
|||||||
|
Passenger capacity
|
2
|
|
|
|
|
standard
|
|
|||||||
|
rang at max speed
|
80 - 100
|
|
|
|
|
standard
|
|
|||||||
|
Max Speed
|
30 km/h
|
|
|
|
|
standard
|
|
|||||||
|
Climb ability
|
20%
|
|
|
|
|
standard
|
|
|||||||
|
(mm) Overall dimensions
|
4500x1340x1990
|
|
|
|
|
standard
|
|
|||||||
|
(mm) Min ground clearance
|
170
|
|
|
|
|
standard
|
/
|
|||||||
|
(mm) Wheelbase
|
3200
|
|
|
|
|
standard
|
/
|
|||||||
|
(mm) Front wheel tread
|
960
|
|
|
|
|
standard
|
/
|
|||||||
|
(mm)Rear wheel tread
|
1000
|
|
|
|
|
standard
|
/
|
|||||||
|
Body
|
PP plastic front body + PP plastic rear body
|
|
|
|
|
standard
|
/
|
|||||||
|
Roof
|
Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
Steering wheel
|
Carbon fiber
|
|
|
|
|
standard
|
/
|
|||||||
|
Windshield
|
foldable
|
|
|
|
|
standard
|
/
|
|||||||
|
Roof strut
|
Steel
|
|
|
|
|
standard
|
/
|
|||||||
|
Seatbelt
|
2-point seatbelt
|
|
|
|
|
standard
|
/
|
|||||||
|
seat
|
Artifical leather
|
|
|
|
|
standard
|
/
|
|||||||
|
1) Backrest and Cushion
|
Waterproof seat cushion and backrest
|
|
|
|
|
standard
|
/
|
|||||||
|
2) armrest
|
Black PP Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
3) Bottom shell
|
PP Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
4) Ice Bucket
|
PP Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
Floor
|
Non-slip floor mat
|
|
|
|
|
standard
|
/
|
|||||||
|
Dashboard
|
F/ R Switch
SOC 110 inch screen |
|
|
|
|
standard
|
/
|
|||||||
|
Beverage holder
|
4 units. PP Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
Side trim
|
PP Plastic
|
|
|
|
|
standard
|
/
|
|||||||
|
Lighting system and horn
|
2 headlights, 2 front turn signals,Front LED Light, 2 taillights( each combined 1 brake light with 1 turn signal), horn.
|
|
|
|
|
standard
|
/
|
|||||||
|
Reversing Alarm
|
Yes
|
|
|
|
|
standard
|
/
|
|||||||
|
Charger
|
Smart Charger
|
|
|
|
|
standard
|
/
|
|||||||
|
streering system
|
Self-adjust rack and pinion
|
|
|
|
|
standard
|
/
|
|||||||
|
Brake System
|
4 wheels disc brake +EM Brake
|
|
|
|
|
standard
|
/
|
|||||||
|
Suspension
|
Front suspension:Front double swingarms suspension
Rear suspension: Rear Tailing arm suspension |
|
|
|
|
standard
|
/
|
|||||||
|
Tire
|
Off-road tires, 23 x 10-12; Aluminium alloy wheel hub
|
|
|
|
|
standard
|
/
|
|||||||
|
Body,Seat,Rim Color
|
Body:Ocean blue
Cushion:Black Rim: Black |
|
|
|
|
standard
|
/
|
|||||||
|
|
Back ball holder
|
|
|
|
|
Optional
|
|
|||||||
|
|
Three-point rear seat belt
|
|
|
|
|
Optional
|
|
|||||||
|
|
Medium bucket three-point seat belt
|
|
|
|
|
Optional
|
|
|||||||
|
|
Up Front
|
|
|
|
|
Optional
|
|
|||||||
|
|
Laminated glass wiper
|
|
|
|
|
Optional
|
|
|||||||
|
|
Front bumper
|
|
|
|
|
Optional
|
|
|||||||
|
|
Long stereo
|
|
|
|
|
Optional
|
|
|||||||
|
|
down side Ambiance lamp
|
|
|
|
|
Optional
|
|
|||||||
|
|
up side Ambiance lamp
|
|
|
|
|
Optional
|
|
|||||||
|
|
Indoor lighting
|
|
|
|
|
Optional
|
|
|||||||
|
|
Endoscope
|
|
|
|
|
Optional
|
|
|||||||
|
|
Front trailer hook
|
|
|
|
|
Optional
|
|
|||||||
|
|
Both pedals
|
|
|
|
|
Optional
|
|
|||||||
|
|
Sand Bottle x1
|
|
|
|
|
Optional
|
|
|||||||
|
|
Refrigerator x1
|
|
|
|
|
Optional
|
|
|||||||
|
|
Ice Bucket
|
|
|
|
|
Optional
|
|
|||||||
|
|
Seat with headrest x 1 pc
|
|
|
|
|
Optional
|
|
|||||||
|
|
Monochrome embroidered seats x 1 pc
|
|
|
|
|
Optional
|
|
|||||||
|
|
Seat embroidered LOG x 1 pc
|
|
|
|
|
Optional
|
|
|||||||
|
|
Off-road tires, 22 x 10-14; Aluminium alloy wheel hub=4 pcs
|
|
|
|
|
Optional
|
|
|||||||
|
|
Soft closure
|
|
|
|
|
Optional
|
|
|||||||
