Quick Details
-
Design Style:
-
Modern
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ALLSTAR
-
Model Number:
-
AH-026
-
Product name:
-
Prefabricated House
-
Name:
-
Steel Structure Container
-
Color:
-
white
-
Door:
-
Steel Door
-
Size:
-
5900*2500*2700mm Accept Custom Size
-
Main material:
-
Steel Structure + Eps Sandwich Panel
-
Window:
-
PVC Sliding Window
-
Wall:
-
50mm/75mm Sandwich Panel
-
Style:
-
Modern Attractive
-
Function:
-
Portable Room Outdoor
Quick Details
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE, Others
-
Application:
-
Hotel
-
Product Type:
-
Container Houses
-
Design Style:
-
Modern
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ALLSTAR
-
Model Number:
-
AH-026
-
Product name:
-
Prefabricated House
-
Name:
-
Steel Structure Container
-
Color:
-
white
-
Door:
-
Steel Door
-
Size:
-
5900*2500*2700mm Accept Custom Size
-
Main material:
-
Steel Structure + Eps Sandwich Panel
-
Window:
-
PVC Sliding Window
-
Wall:
-
50mm/75mm Sandwich Panel
-
Style:
-
Modern Attractive
-
Function:
-
Portable Room Outdoor
Product Description
1. Can be usedas dormitory temporary hospital toilet office storage room etc
2).Can be installed in a short time assembled by bolts with a high intensity
3. Can be used repeatedly with a life span of more than 15 years
4. With a well-sealed and reliable structure water-proof fire-resistant moisture-proof and anti-corrosive
5.With supporting facilities such as washbasin shower air-conditioner, socket and so on;
6.The special design enables to carry this container house in a whole without damages, so it's quite suitable for movable
projects.
projects.
|
|
20ft container house
|
|
40ft container house
|
|
||
|
inner length/
external length
|
5.90m/6.00m
|
|
11.90m/12.05m
|
|
||
|
inner width/
external width
(two options)
|
A.2.35m/2.45m
B.2.60m/2.85m
|
|
A.2.35m/2.45m
B.2.60m/2.85m
|
|
||
|
inner height/
external height
|
2.60m/2.70m
|
|
2.60m/2.70m
|
|
||
|
weight
|
1800kg per unit
|
|
2950kg per unit
|
|
||
|
color
|
customer-made
|
|
|
|
||
|
|
|
|
|
|
||
|
load
(kn/m2)
|
Base plate:3.0
|
|
|
|
||
|
|
Roof panel:1.5
|
|
|
|
||
|
|
Wind force:0.6
|
|
|
|
||
|
Sound insulation(db)
|
Base plate:30~35
|
|
|
|
||
|
|
Roof panel:30~35
|
|
|
|
||
|
|
Wind force:20~25
|
|
|
|
||
|
heat transfer
coefficient(W/m2K)
|
Base plate:0.46
|
|
|
|
||
|
|
Roof panel:0.64
|
|
|
|
||
|
|
Wall panel:0.47
|
|
|
|
||
Advantages:
1. High Quality: Succeed Certificated by JIS , (another company is Baosteel)
2. All Size Available: Regular or unusual
3. Cooperative Partners: All kinds of steel mails(state-owned, medium, small size) with all level products
4. Mature Teamwork: Complete and orderly team structure, including rich-experienced leader and energetic fresh blood
5. Export Ability: Having good exporting ability and relative exporting qualifications
6. Reasonable Price: Able to give you best price
7. Multiple Payment Terms: T/T, T/T and L/C, T/T,etc
8. Delivery: Delivery on time
2. All Size Available: Regular or unusual
3. Cooperative Partners: All kinds of steel mails(state-owned, medium, small size) with all level products
4. Mature Teamwork: Complete and orderly team structure, including rich-experienced leader and energetic fresh blood
5. Export Ability: Having good exporting ability and relative exporting qualifications
6. Reasonable Price: Able to give you best price
7. Multiple Payment Terms: T/T, T/T and L/C, T/T,etc
8. Delivery: Delivery on time
Product Overviews
Frame
|
20ft keel
(two options)
|
C100mm*100mm*2.5mm steel purlin
C160mm*160mm*3.0mm steel purlin
|
|
|
|
|||
|
|
|
|
|
|
|||
|
40ft keel
(two options)
|
C100mm*100mm*3.0mm steel purlin
C160mm*160mm*3.5mm steel purlin
|
|
|
|
|||
|
|
|
|
|
|
|||
Wall
|
insulation material
(thickness depends on customer)
|
50mm/75mm/100mm/150mm thickness sandwich panel
|
|
|
|
|||
|
Wall inside
|
0.5mm color steel sheet
|
|
|
|
|||
|
Wall outside
|
0.5mm color steel sheet
|
|
|
|
|||
|
color outside
|
customer-made
|
|
|
|
|||
|
color inside
|
White
|
|
|
|
|||
Roof
|
outside sheet
|
0.5mm steel sheet
|
|
|
|
|||
|
insulation layer
(thickness depends on customer)
|
50mm/75mm/100mm/150mm thickness sandwich panel
|
|
|
|
|||
|
keel
|
C30mm*40mm*3.0mm steel purlin
|
|
|
|
|||
|
ceiling
|
3mm thickness PVC ceiling (light gray)
|
|
|
|
|||
Floor
|
Floor bottom board
|
1.0mm thickness steel sheet
|
|
|
|
|||
|
insulation layer
|
18mm thickness fire protection
|
|
|
|
|||
|
keel
|
C30mm*80mm*3.0mm steel purlin
|
|
|
|
|||
windows and door
|
window
(20ft 2pcs)
(40ft 4pcs)
|
900*1200mm
|
|
|
|
|||
|
door
(20ft 1pcs)
(40ft 3pcs)
|
875*2000mm
|
|
|
|
|||
Electronic installations
|
|
20ft
|
|
40ft
|
|
||
|
Fluorescent lighting(36W)
|
2pcs
|
|
4pcs
|
|
||
|
switch
|
1pcs
|
|
2pcs
|
|
||
|
400V/5-pole3*32CEE plug-in
|
1pcs
(outside in the frame )
|
|
2pcs
(outside in the frame)
|
|
||
|
fuse-board with FI
relay & miniiature circuit breakers
|
1pcs
|
|
2pcs
|
|
||
Product picture
20ft flat pack container hosue
other container hosue
Packing & Delivery
Our Company
FAQ
A: We have been awarded the certificate by CE, BV,SGS.
2Q: What is the lifespan and warranty period?
A: CKD Container house: 15-20 years, Flat pack container house 20-25 Years.Folding container house 20-25 years.Expandable
container house 20-30 years
container house 20-30 years
A: CKD Container house is direct packing, Flat pack container house is flat packing ,Folding container house is also flat packing.
Expandable container house is folding
4Q: What’s you payment terms?
A: 40%TT deposit and 60%TT balance payment.
