Quick Details
-
Application:
-
Construction
-
Rated Lifting Moment:
-
350kn.m
-
Span:
-
5.1*4.95m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
heng wang
-
Marketing Type:
-
New Product
-
Weight (KG):
-
16000 kg
-
Product name:
-
12 ton truck crane Dongfeng 8X4 16 Tons Truck Mounted Crane
-
Engine:
-
yuchai
-
Max. travel speed:
-
75km/h
-
Boom type:
-
7m*5-section U-shaped anti-folding boom.
-
Chassis brand:
-
DongFeng.FAW.Foton.Sino.JAC.IVECO.Shacman
-
Capacity:
-
8--25 Ton Truck Crane
-
Crane type:
-
Truck Crane Mobile Crane Hydraulic Crane
-
Emission standard:
-
Euro3/4
-
Keyword:
-
12 Ton Truck Mounted Crane
-
Certification:
-
ISO
Quick Details
-
Rated Loading Capacity:
-
12000kg
-
Max. Lifting Height:
-
29m
-
Engine Brand:
-
YUCHAI
-
Application:
-
Construction
-
Rated Lifting Moment:
-
350kn.m
-
Span:
-
5.1*4.95m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
heng wang
-
Marketing Type:
-
New Product
-
Weight (KG):
-
16000 kg
-
Product name:
-
12 ton truck crane Dongfeng 8X4 16 Tons Truck Mounted Crane
-
Engine:
-
yuchai
-
Max. travel speed:
-
75km/h
-
Boom type:
-
7m*5-section U-shaped anti-folding boom.
-
Chassis brand:
-
DongFeng.FAW.Foton.Sino.JAC.IVECO.Shacman
-
Capacity:
-
8--25 Ton Truck Crane
-
Crane type:
-
Truck Crane Mobile Crane Hydraulic Crane
-
Emission standard:
-
Euro3/4
-
Keyword:
-
12 Ton Truck Mounted Crane
-
Certification:
-
ISO
Product Description
Technical Parameters
|
Model
|
HWQY12T
|
Slewing bearing
|
Internal tooth 1.4m
|
|
Power
|
95KW（130Hp）
|
Slewing mechanism
|
planetary steering
|
|
Weight
|
13000kg
|
Outrigger
|
5 full hydraulic outriggers (double section)
|
|
Overall dimensions
|
10.2m*2.35m*3.4m
|
Outrigger span
|
6250mm
|
|
wheelbase
|
3800mm
|
Outrigger span (single)
|
5800mm
|
|
Maximum rated lifting weight
|
12000kg
|
Protector
|
biliateral pilot-controlled valve
|
|
Maximum lifting height
|
30m、35m
|
working lamp
|
2pcs
|
|
Engine model
|
4105
|
Hydraulic pump
|
Double pump 50/40
|
|
Gearbox model
|
6-speed transmission
|
Oil electric amphibious
|
15KW IP6-pole motor 40/32
|
|
Braking System
|
automatically air-cut brake
|
Boom structure type
|
7m x 6section
|
|
Steering mechanism
|
Hydraulic Power Steering
|
Main hoisting mechanism
|
12T winch
|
|
Boom size
|
520mm*350mm
|
Secondary hoisting mechanism
|
8T winch
|
