- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Hangzhou, Zhejiang, China
-
Brand Name:
-
VisionDatum
-
Model Number:
-
LEO720s-520
-
Video Compression Format:
-
/
-
Data Storage Options:
-
pc
-
Application:
-
Factory Automation, Visual inspection, golf swing
-
Sensor Size:
-
1/2.9''
-
Sensor Name:
-
SONY IMX287
-
Sensor Technology:
-
CMOS, GLOBLE shutter
-
Mono/Color:
-
Mono/color
-
Frame Rate:
-
300fps/520 fps
-
Pixel Size:
-
6.9
-
Data Bits:
-
8bit / 10bit/12bit
-
Lens Mount:
-
C Mount
-
Interface:
-
USB 3.0
-
Dynamic Range:
-
60dB
Quick Details
-
Special Features:
-
Motion Detection, Face Recognition, GLOBLE shutter
-
Function:
-
Wide Angle, High speed, Motion capture
-
Customized support:
-
Online technical support, OEM, ODM
-
Place of Origin:
-
Hangzhou, Zhejiang, China
-
Brand Name:
-
VisionDatum
-
Model Number:
-
LEO720s-520
-
Video Compression Format:
-
/
-
Data Storage Options:
-
pc
-
Application:
-
Factory Automation, Visual inspection, golf swing
-
Sensor Size:
-
1/2.9''
-
Sensor Name:
-
SONY IMX287
-
Sensor Technology:
-
CMOS, GLOBLE shutter
-
Mono/Color:
-
Mono/color
-
Frame Rate:
-
300fps/520 fps
-
Pixel Size:
-
6.9
-
Data Bits:
-
8bit / 10bit/12bit
-
Lens Mount:
-
C Mount
-
Interface:
-
USB 3.0
-
Dynamic Range:
-
60dB
-Use popular Sony
IMX287
-High frame rate 500fps
-USB3.0 interface, pulg &paly
-Small size, easy to install
-Supports triggering and adjustable exposure time
LEO2 cameras support Four-sided Installation and larger temperature width design.
"-Lite": Small shell;
"-HR": Higher dynamic range;
"-p": supports lossless compression;
|
Model
|
Sensor
|
Frame Rate
|
Shutter Type
|
Interface
|
Image Color
|
|
LEO 720S-520UC
|
IMX287
|
520FPS
|
Global
|
USB3.0
|
Color
|
|
LEO 720S-520UM
|
IMX287
|
520FPS
|
Global
|
USB3.0
|
Mono
|
|
LEO 720S-310GC
|
IMX287
|
310FPS
|
Global
|
GigE
|
Color
|
|
LEO 720S-310GM
|
IMX287
|
310FPS
|
Global
|
GigE
|
Mono
|
|
Resolution
|
720x540
|
|
|
|
|||
|
Image Format
|
Monochrome： Mono8/10/10p/12/12p Color：Mono 8/10/12,Bayer RG 8/10/10p/12/12p,YUV422Packed,YUV422_YUYV_Packed,RGB 8,BGR 8
|
|
|
|
|||
|
Operating System
|
Windows,Linux
|
|
|
|
|||
|
Driver
|
LEO Series Camera Software Suite (iDatum) or 3rd party USB3/GigE Vision Software
|
|
|
|
|||
|
Synchronization
|
Via hardware trigger、software trigger or free run mode
|
|
|
|
|||
|
Conformity
|
USB3/GigE Vision,GenICam
|
|
|
|
|||
