Quick Details
-
Productivity:
-
6M³/H
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
YG/OEM
-
Weight:
-
600 kg
-
Dimension(L*W*H):
-
1800*700*1100mm
-
Product name:
-
Concrete Pump
-
Keyword:
-
Concrete Pumping Equipment
-
Concrete pump type:
-
Diesel Pump
-
Type:
-
Concrete Pump
-
Color:
-
Customer Request
-
Usage:
-
Grouting Cement
-
Feature:
-
High Efficience
-
Function:
-
Concstruction
-
Work efficiency:
-
6 - 22 Cubic Metre/h
-
Package:
-
Wooden Case
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
20M
-
Max. horizontal conveying distance:
-
50M
-
Productivity:
-
6M³/H
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
YG/OEM
-
Weight:
-
600 kg
-
Dimension(L*W*H):
-
1800*700*1100mm
-
Product name:
-
Concrete Pump
-
Keyword:
-
Concrete Pumping Equipment
-
Concrete pump type:
-
Diesel Pump
-
Type:
-
Concrete Pump
-
Color:
-
Customer Request
-
Usage:
-
Grouting Cement
-
Feature:
-
High Efficience
-
Function:
-
Concstruction
-
Work efficiency:
-
6 - 22 Cubic Metre/h
-
Package:
-
Wooden Case
Product Description
Newly developed concrete pump can delivery concrete, mortar, cement, fireproof material, etc. It is suitable for fine stone concrete transportation to higher construction floor column pouring. It is the smallest concrete pump in China, mainly for some special construction conditions or narrow sites, which is inconvenience in work or difficult to complete the construction schedule.
Product Paramenters
|
Model
|
YG-10
|
YG-20
|
YG-30
|
YG-40
|
|
Mortor power:
|
15KW
|
22KW
|
37KW
|
45KW
|
|
Maximum outlet pressure:
|
15mpa
|
5-18mpa
|
15-18mpa
|
23mpa
|
|
Maximum theoretical throughput:
|
6m3/h
|
12m3/h
|
15-18m3/h
|
20-22m3/h
|
|
Maximum particle size of aggregate:
|
5-15mm
|
5-20mm
|
≤20mm
|
20mm
|
|
Horizontal conveying distance:
|
50m
|
80m
|
160mm
|
260m
|
|
Vertical conveying distance:
|
20m
|
40m
|
80mm
|
120m
|
|
Diameter of delivery pipe:
|
80mm
|
80mm
|
φ80（100）mm
|
φ100 (80) mm
|
|
Total Weight:
|
600kg
|
1600kg
|
2200kg
|
2400kg
|
|
Dimensions(mm):
|
1800*700*1100
|
3400*1200*1600
|
3800*1500*1600
|
4000*1500*1550
|
Product Display
Product Real Shot
Product Usage
Product Packaging
Packaging Details
1. Out package: Standard marine export plwywood cases;
2. Innner package:Stretch film and plastic film for humidity;
3. Customized according to your requirement.
Delivery Time
Within one week
Shipping
Port : Tianjin, Qingdao, Shanghai or other ports according to your requirements.
Sea freight : FOB/CIF/DDU quotation are all available.
Transport method : By logistics; by automobile; by train; by shipping; by air etc.
2. Innner package:Stretch film and plastic film for humidity;
3. Customized according to your requirement.
Delivery Time
Within one week
Shipping
Port : Tianjin, Qingdao, Shanghai or other ports according to your requirements.
Sea freight : FOB/CIF/DDU quotation are all available.
Transport method : By logistics; by automobile; by train; by shipping; by air etc.
