Quick Details
-
Model Number:
-
KSP-6W
-
Output Frequency:
-
50/60Hz
-
Product Name:
-
24V0.25A constant voltage led driver
-
Output:
-
12V/24V/36V/48V 6W
-
Certification:
-
RU cRU CE RoHS ...
-
Material:
-
Plastic Case
-
Warranty:
-
2 Years
-
Protection:
-
OCP, OVP, SCP, OTP
-
Efficiency:
-
≥ 90%
-
Application:
-
LED Strip Light,Pendants, Linears,Cove Lights
-
Color:
-
White
-
IP Rate:
-
IP20
Quick Details
-
Warranty(Year):
-
3-Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KSPOWER
-
Model Number:
-
KSP-6W
-
Output Frequency:
-
50/60Hz
-
Product Name:
-
24V0.25A constant voltage led driver
-
Output:
-
12V/24V/36V/48V 6W
-
Certification:
-
RU cRU CE RoHS ...
-
Material:
-
Plastic Case
-
Warranty:
-
2 Years
-
Protection:
-
OCP, OVP, SCP, OTP
-
Efficiency:
-
≥ 90%
-
Application:
-
LED Strip Light,Pendants, Linears,Cove Lights
-
Color:
-
White
-
IP Rate:
-
IP20
Products Description
high quality thin industry Led Power Supply 24V 0.25A 6W small electronic constant voltage led driver for Christmas led lights
The KSPOWER - P series AC DC led driver 6 Watt is one constant voltage solution, rectangular plastic case with IP20 level, single channel, accept AC input voltage range from 100V to 240V, and output voltage range from 5V to 48V. The led power transformer is one Class II power supply, great ideal for led strip lights and other low voltage devices such as security cameras audio, video gear cabinets light, Mr16, Mr11, G4 bulb and more. The class 2 led driver is ultra-small size, length 1.66in/width 1.54in/height 0.79in, with certification RU/cRU, CE, ROHS. The led dc transfromer is built-in intelligent chip-set, anti-thunder,with automatic thermal & overload cut-off, short circuit protection function.
|
Input Voltage
|
100-240 Volts AC 50/60Hz
|
|
|
|
|||
|
NO.
|
KSP-6W12
|
KSP-6W24
|
KSP-6W36
|
KSP-6W48
|
|||
|
Output Voltage
|
12V
|
24V
|
36V
|
48V
|
|||
|
Rated Current(full load)
|
500mA
|
250mA
|
167mA
|
125mA
|
|||
|
Rated Power
|
6W
|
|
|
|
|||
|
Working Temperature
|
-40℃ to +50℃
|
|
|
|
|||
|
Certification
|
UL RU cRU CE RoHS ...
|
|
|
|
|||
|
Dimension(L*W*H)
|
42*40*20mm / 1.66*1.54*0.79in
|
|
|
|
|||
Features:
* Single channel & Constant Voltage switch power supply
* Low weight, small volume
* Full Load Burn-in Test
* Automatic protection for short circuit / overload / over voltage
* 12 Months Warranty
* IP20 rated for indoor use
* Safe with fully insulated connectors type: Screw Terminal
* Easy to install, mount, and wire
Note：Any custom label/package/case is acceptable, provide OEM and ODM service
* Low weight, small volume
* Full Load Burn-in Test
* Automatic protection for short circuit / overload / over voltage
* 12 Months Warranty
* IP20 rated for indoor use
* Safe with fully insulated connectors type: Screw Terminal
* Easy to install, mount, and wire
Note：Any custom label/package/case is acceptable, provide OEM and ODM service
Show Details
Connect Drawing
Product packaging
1. Each one put in one small inner brown box ，
then 200 pcs put in one standard carton.
2. Sample is available.
3. Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
2. Sample is available.
3. Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
|
Package
|
Piece/Carton(pcs)
|
|
Piece Weight(KG)
|
|
||
|
OEM package
|
200
|
|
0.045
|
|
||
|
Dimension/Brown Box(mm)
|
Dimension/Carton(mm)
|
|
Gross Weight/Carton(KG)
|
|
||
|
43*22*60
|
490*235*145
|
|
10
|
|
||
