Quick Details
-
Brand Name:
-
Xindun Power
-
Model Number:
-
XD-Lithium battery
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
24kg~90kg (Depend on Model)
-
The charging ratio:
-
/
-
The discharge rate:
-
/
-
Electric Energy:
-
5 Wh
-
Installation:
-
wall-mounted
-
Working Temperature:
-
-20℃~ + 58℃
-
Maximum Working Altitude:
-
4000 m(≥2000m derating)
-
Installation Environment:
-
Indoor scenario
-
Working Relative Humidity:
-
5%~95%
-
Battery type:
-
Lifepo4/lithium Battery
-
Keywords:
-
24 volts battery
-
OEM/ODM:
-
Accept OEM&ODM
-
Cell:
-
LiFePO4/Lithium ion battery
-
Warranty:
-
5 Years
Quick Details
-
Storage Type:
-
Normal Storage
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, Solar Energy Storage Systems
-
Brand Name:
-
Xindun Power
-
Model Number:
-
XD-Lithium battery
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
24kg~90kg (Depend on Model)
-
The charging ratio:
-
/
-
The discharge rate:
-
/
-
Electric Energy:
-
5 Wh
-
Installation:
-
wall-mounted
-
Working Temperature:
-
-20℃~ + 58℃
-
Maximum Working Altitude:
-
4000 m(≥2000m derating)
-
Installation Environment:
-
Indoor scenario
-
Working Relative Humidity:
-
5%~95%
-
Battery type:
-
Lifepo4/lithium Battery
-
Keywords:
-
24 volts battery
-
OEM/ODM:
-
Accept OEM&ODM
-
Cell:
-
LiFePO4/Lithium ion battery
-
Warranty:
-
5 Years
Product Description
Product Detail
Specification
|
Performance
|
|
|
|
|||
|
Battery Model
|
XFE100P10
|
XFG100P10
|
XFG100PC7/DS
|
|||
|
Capacity
|
25.6V100AH （100A）
|
51.2V100AH （100A）
|
51.2V200AH (200A)
|
|||
|
Battery Total Energy
|
2.5kwh
|
5kwh
|
10kwh
|
|||
|
Rated Energy
|
2.5kw
|
5.1kw
|
8.9kw
|
|||
|
Peak Energy
|
3kw
|
6kw
|
10kw
|
|||
|
Rated Voltage（DC）
|
25.6V
|
51.2V
|
51.2V
|
|||
|
Allowable BMS Load Current
|
100A
|
100A
|
200A
|
|||
|
Battery Voltage Range(DC)
|
22.4V~29.2V
|
44.8V~58.4V
|
44.8V~58.4V
|
|||
|
Inverter Operatig Voltage Range(single-phase）
|
220V~240V
|
220V~240V
|
220V~240V
|
|||
|
Inverter Operating Voltage Range thr ee-phase)
|
340~460V
|
340~460V
|
340~460V
|
|||
|
Communication
|
|
|
|
|||
|
Display
|
SOC status indication, LED indicator screen
|
|
|
|||
|
Protocol
|
RS485 /RS232/ CAN (Series parallel connection with either option)
|
|
|
|||
|
Dimension（L x W x H）
|
370*160*400mm
|
370*160*600mm
|
500*160*850mm
|
|||
|
Weight（ Accessories Included）
|
~24Kg
|
~45Kg
|
~102Kg
|
|||
|
Installation
|
wall-mounted or floor-mounted
|
|
|
|||
|
Working Temperature
|
-20℃～ + 55℃
|
|
|
|||
|
Maximum Working Altitude
|
4000 m（≥2000m derating）
|
|
|
|||
|
Installation Environment
|
Indoor scenario
|
|
|
|||
|
Working Relative Humidity
|
5%～95%
|
|
|
|||
Wiring Diagram
