- Product Details
- {{item.text}}
Quick Details
-
Rated voltage:
-
320VDC
-
tailgate height:
-
550MM
-
Configure the battery:
-
42.5kwh
-
controller:
-
Steering control / does not change driving habits
-
Rated Speed:
-
6000rpm
-
propeller:
-
16.5" x 15" three-blade metal paddle
-
Motor:
-
Permanent magnet synchronous/non-direct drive
-
Power:
-
60p
Quick Details
-
Voltage:
-
320VDC
-
Product Name:
-
Brogen 45kw 60P electric boat motor for electric propulsion
-
Rated power:
-
45kw
-
Rated voltage:
-
320VDC
-
tailgate height:
-
550MM
-
Configure the battery:
-
42.5kwh
-
controller:
-
Steering control / does not change driving habits
-
Rated Speed:
-
6000rpm
-
propeller:
-
16.5" x 15" three-blade metal paddle
-
Motor:
-
Permanent magnet synchronous/non-direct drive
-
Power:
-
60p
Products Description
Brogen 45kw 60P electric boat motor for electric propulsion
|
T
ype
|
Electric propulsion
|
|
Input power
|
45kw
|
|
Rated voltage
|
320V
|
|
Configure the battery
|
42.5kwh
|
|
Controller
|
Steering control / does not change driving habits
|
|
Motor
|
Permanent magnet synchronous/non-direct drive
|
|
Battery life
|
4h @14km/h
|
|
Battery life
|
2.5h @25km/h
|
|
Battery life
|
1h @38km/h
|
|
Electric propulsion
|
60P
|
|
Rated speed
|
6000RPM (gear ratio 27:13)
|
|
Weight
|
Machine weight 38kg Battery weight 70kg
|
|
Propeller
|
16.5" x 15" three-blade metal paddle
|
|
Tailgate height
|
550MM
|
Advantages:
New energy electric ship solutions,
Safe, Environmentally Friendly, Quiet, Comfortable, Zero Emission
Product Description:
Electric outboard motor uses a permanent magnet synchronous water
cooled motor as the driving power and is equipped with a lithium iron
phosphate power battery as the power source. The whole system is safe,
reliable and durable, environmentally friendly, and energy-saving, and the use
and maintenance cost is very low. The motor control and safety protection
functions are highly intelligent, and the operation is simple and easy to learn.
Compared with fuel and gas engines, the advantages are quite obvious.
