Quick Details
-
Brand Name:
-
lingfeng
-
Model Number:
-
120*600
-
Voltage:
-
360v
-
Power:
-
8000-15000
-
Dimension(L*W*H):
-
2.0m*1.0m*1.0m
-
Weight:
-
2t
-
Features:
-
easy operation ; automatic
-
Warranty:
-
one year
-
Certification:
-
iso9001
-
business scope:
-
world wide
-
exporting country:
-
over 20 countries
-
feature:
-
efficient
-
No.hole:
-
5
-
shape of the hole:
-
circle
-
diameter of the hole:
-
76mm
-
color:
-
yellow or gray
-
use1:
-
prefab houses
-
use2:
-
civil building
-
use3:
-
tiny house
Quick Details
-
Application:
-
prefab building construction
-
Production Capacity:
-
65-70m/h
-
Place of Origin:
-
China
-
Brand Name:
-
lingfeng
-
Model Number:
-
120*600
-
Voltage:
-
360v
-
Power:
-
8000-15000
-
Dimension(L*W*H):
-
2.0m*1.0m*1.0m
-
Weight:
-
2t
-
Features:
-
easy operation ; automatic
-
Warranty:
-
one year
-
Certification:
-
iso9001
-
business scope:
-
world wide
-
exporting country:
-
over 20 countries
-
feature:
-
efficient
-
No.hole:
-
5
-
shape of the hole:
-
circle
-
diameter of the hole:
-
76mm
-
color:
-
yellow or gray
-
use1:
-
prefab houses
-
use2:
-
civil building
-
use3:
-
tiny house
The description of Ling-Feng Precast Concrete Hollow Core Lightweight Wall Panel Forming Machine
Ling-Feng Precast Concrete Hollow Core Lightweight Wall Panel Forming Machine is a specialized machine to poduct non-load bearing external wall slab by extrusion method, widely used for the external partition of building, such as office building, civil building and civil apartment. The lightweight wall panel making machine is characterized with low cost, lightweight and easy operation.
Precast prestressed concrete hollow core lightweight wall panel making machine-
| Model |
Width (mm) |
Thickness (mm) |
No.& Dia of holes (mm) |
Speed (mm/min) |
Main Motor (kw) |
Vibrator (kw) |
Dimension (mm) |
Weight (kg) |
| 80*600 | 595±2 | 90±1 | 8*43 | ≥1400 | Y112M-4 | ZW5A-0.8 | 2250*980*170 | 1100 |
| 90*600 | 595±2 | 90±1 | 7*58 | ≥1400 | Y112M-4 | ZW5A-0.8 | 2250*980*170 | 1100 |
| 120*600 | 595±2 | 120±1 | 5*85 | ≥1400 | Y112M-4 | ZW5A-0.8 | 2250*980*730 | 1300 |
| 180*600 | 595±2 | 180±1 | 4*110 | ≥1400 | Y132S-4 | ZW10B-1.1 | 2250*980*820 | 2000 |
Production process of the prestressed lightweight concrete wall panel forming machine
1.the design of the lightweight concrete wall panel forming machine‘s motor stander is very stable
2. the lightweight concrete wall panel forming machine‘s eccentric wheel is thicker than others
3. front wheel a t the very top of the lightweight wall panel machine so can better make sure keep balance
4.there are three places in which we weld alloy,side board,and our alloy's quality is excellent,the working life can up to 8-10 ten thousand meters .
5.our vibrator come from HeNan ANYANG ,which is the best factory manufacture the machines in China
Concrete fence machine ---Wet cast, steel reinforced concrete fence posts which are suitable for domestic panel fencing. Concrete Slotted fence posts are the long lasting alternative to timber posts as each post has four internal steel reinforcing bars. Concrete fence posts provide strength and durability to your fencing and are not susceptible to rot in the ground.
Concrete fence machine---All the concrete fence posts contain steel reinforcing to the required specification. We carry large stocks of our complete range of concrete posts, concrete gravel boards and other products.
Concrete fence machine---Fencing panels will fit into the slotted fence posts.Concrete fence posts for chainlink, welded mesh, timber fencing, strained wire fencing and all other types of concrete fencing products. These are manufactured in our own factory by automated machinery.
