Quick Details
-
Warranty:
-
1 year
-
Certificate:
-
CE/FCC/Rohs/ISO9001
-
Type:
-
AHD HDD Mobile DVR
-
Resolution:
-
Support 1080P/720P/D1/CIF, MAX 8 channels 1080P
-
Video Compression:
-
H.265 Compression Mode
-
Video input:
-
8CH AHD1080P, aviation connector.
-
Video output:
-
2CH CVBS + VGA output for optional, 1.0Vp-p, 75Ω
-
Storage:
-
2.5'' HDD+ SD Card,each max 2TB HDD + 128GB SD Card
-
GPS 3G 4G Wifi:
-
Optional
-
Software:
-
CMSV6
Quick Details
-
Brand Name:
-
Further-Technology
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
FL-H10
-
Warranty:
-
1 year
-
Certificate:
-
CE/FCC/Rohs/ISO9001
-
Type:
-
AHD HDD Mobile DVR
-
Resolution:
-
Support 1080P/720P/D1/CIF, MAX 8 channels 1080P
-
Video Compression:
-
H.265 Compression Mode
-
Video input:
-
8CH AHD1080P, aviation connector.
-
Video output:
-
2CH CVBS + VGA output for optional, 1.0Vp-p, 75Ω
-
Storage:
-
2.5'' HDD+ SD Card,each max 2TB HDD + 128GB SD Card
-
GPS 3G 4G Wifi:
-
Optional
-
Software:
-
CMSV6
Details Images
|
Item
|
Parameter
|
Description
|
|
System
|
Operational language
|
Chinese. English, Others (customizable)
|
|
|
Operation interface
|
Graphical menu operation interface (OSD menu)
|
|
|
Password security
|
Two-level management of user password and
administrator password |
|
Video
|
Video input
|
4/8 video input
|
|
|
Video output
|
There are two video output modes of VGA and aviation head interface
|
|
|
Video resolution
|
Support 1080P. 720P, D1, HD1, CIF, etc
|
|
|
Video loop recording
|
Support SD card automatic loop recording and loop overlay (auto default)
|
|
|
Video mode
|
Support boot recording, timing recording, alarm (trigger) recording
|
|
|
Image compression
|
H264/H265
|
|
Display
|
Preview features
|
Supports single and multi-view
|
|
|
OSD overlay display
|
Channel name, time, recording status, resolution, license plate, GPS information, etc
|
|
Alarm
|
IO alarm
|
4 IO alarm inputs, with alarm linkage function
|
|
Communication interface
|
RS232 interface
|
1CH RS232, expandable card machine, oil sensor, LED advertising screen, etc
|
|
|
RS485 interface
|
1-way 485 interface, expandable gimbal
|
|
AI capabilities
(Extensible) |
Passenger counting
|
1 door passenger counting
|
|
|
|
2 doors passenger counting
|
|
|
|
3 doors passenger counting
|
|
|
|
4 doors passenger counting
|
|
|
DMS
|
Fatigue (closed eyes, hatcher) detection alarm
|
|
|
|
Occlusion camera detection alarm
|
|
|
|
Receiving and receiving phone calls to detect alarms
|
|
|
|
Face loss detection alarm
|
|
|
|
Distraction detection alarm
|
|
|
|
Smoking detection alarm
|
|
|
ADAS
|
Occlusion camera detection alarm
|
|
|
|
Lane departure detection alarm
|
|
|
|
Pedestrian detection warning
|
|
|
|
Vehicle distance detection and warning
|
|
|
BSD
|
Left blind zone detection alarm
|
|
|
|
Right blind zone detection alarm
|
|
Platform
|
Remote monitoring
platform |
Real-time monitoring, monitoring intercom, playback, video, high-definition screenshots, GPS data, alarm data upload
|
|
Others
|
Power consumption
|
≤10W
|
|
|
Operating temperature
|
-20℃ to +70℃
|
|
|
Operating humidity
|
20% to 80%
|
|
|
Size
|
161 （D）* 159（W）* 63（H） mm
|
|
|
Net weight
|
1.119KG
|
|
|
Power input
|
DC +10V - +36V
|
Accessory
Installation
H
10 2 Doors People Counter Work Diagram
Support 2 doors people counter plus 4 general Cameras，s
upport mobile APP remote monitoring and connecting, support mobile phone 4G call function.
Accurate statistics
It can accurately identify the number of people getting on and off the train and make accurate statistics. The platform can monitor the number of passengers in real time.
Applications
The client can generates data
Users can remotely manage and view all vehicles through
the app in the mobile phone and windows .
Can provide security for the vehicle, real-time monitoring of vehicle data
