Voltage Rating
|
DC
|
|
1500V/AC
|
1.0kv
|
|
Insulation resistance
|
1000Ω/km
|
|
Test voltage
|
AC6.5kv 50Hz 5min
|
|
Temperature Rating
|
-40°C--+90°C
|
|
Flame retardant
|
EN 60332.1-1
|
|
Standards
|
RoHS CE Tuv
|
|
Cross section(nxmm2)
|
Conductor (mm)
|
Outer (mm)
|
Current-carrying
capacity [A] at 60°C
|
Conductor resistance
kΩ/ km at 20°C
|
cable code
|
|
1x1.5
|
1.4
|
4.2
|
30
|
13.7
|
PV302515
|
|
1x2.5
|
1.8
|
5.0
|
42
|
8.21
|
PV502525
|
|
1x4.0
|
2.2
|
5.2
|
55
|
5.09
|
PV562940
|
|
1x6.0
|
2.8
|
5.8
|
70
|
3.39
|
PV842960
|
|
1x10.0
|
4.0
|
7.5
|
98
|
1.95
|
PV142301
|
|
1x16.0
|
5.0
|
8.9
|
132
|
1.24
|
PV228301
|
|
1x25.0
|
6.2
|
10.9
|
176
|
0.795
|
PV361302
|
|
1x35.0
|
7.3
|
12.8
|
218
|
0.565
|
PV525303
|
|
1x50.0
|
8.8
|
14.3
|
280
|
0.393
|
PV720305
|
|
1x70.0
|
11.0
|
16.5
|
350
|
0.277
|
PV988307
|
|
1x95.0
|
12.3
|
18.2
|
410
|
0.210
|
PV134930
|
|
1x120.0
|
14.1
|
20.2
|
480
|
0.164
|
PV169130
|
