1. It saves 10-30% energy than the air compressor produced by ordinary manufacturers.
2. It is widely used in medical oxygen generator and ventilator .
3. A large number of high-speed train and automobile application cases, supporting - 41 to 70 ºC, 0-6000 meters above sea level .
4. Medium and high-end quality, with more than 7000 hours of trouble free operation for conventional products and more than 15000
hours of trouble free operation for high-end products.
5. Simple operation, convenient maintenance and remote guidance.
6. Faster delivery time, generally completed within 25 days within 1000 PCs.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
12V
-
Dimension(L*W*H):
-
140* 89 * 116mm
-
Weight:
-
1.6Kg
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE Certification
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
COMBESTAIR
-
Model Number:
-
BST 260AF
-
Voltage:
-
12V
-
Dimension(L*W*H):
-
140* 89 * 116mm
-
Weight:
-
1.6Kg
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE Certification
Product Description
|
Model
|
BST260AF/BS
|
|
Voltage/frequency (V/Hz)
|
220-240V/50Hz;110-115v/60Hz
|
|
Input power(W)
|
≤260
|
|
Speed (r/min)
|
≥1380
|
|
Rated pressure (KPa)
|
206.8KPa
|
|
Max pressure(KPa)
|
300KPa
|
|
Restart pressure (KPa)
|
0KPa
|
|
Rated volume flow (m3/h)
|
2.6m3/h@206.8KPa;
|
|
Noise dB(A)
|
≤58dB(A)
|
|
Ambient temperature ºC
|
-5~40 ºC
|
|
Insulation Class
|
B
|
|
Cold insulation resistance (MΩ)
|
≥100MΩ
|
|
Thermal protector
|
Automatic reset 135±5ºC
|
|
Capacitance (μF)
|
6 μF±5%
|
|
Net weight (Kg)
|
5.4Kg
|
|
Installation Dimensions (mm)
|
83×127mm(Install thread 4-M6)
|
|
External Dimensions (mm)
|
214×103×163 mm
|
|
Oxygen generator
|
1-3L
|
|
Typical application
|
|
|
|
Respirator (ventilator)
|
oxygenerator
|
|
|
Disinfectant sprayer
|
Blood analyzer
|
|
|
Clinical aspirator
|
Dialysis / hemodialysis
|
|
|
Dental vacuum drying oven
|
Air suspension system
|
|
|
Vending machines / coffee blenders and coffee machines
|
Massage chair
|
|
|
Chromatographic analyzer
|
Teaching instrument platform
|
|
|
On board access control system
|
Airborne oxygen generator
|
|
Details Images
Why Choose Us
Why choose besten air compressor
Parts introduction
Parts chart
|
serial
number |
Code number
|
Name and specification
|
Quantity
|
Material
|
Note
|
|
1
|
212010109
|
Fan cover
|
2
|
Reinforced nylon 1010
|
|
|
2
|
212010106
|
Left fan
|
1
|
Reinforced nylon 1010
|
|
|
3
|
212010101
|
Left box
|
1
|
Die-cast aluminum alloy YL104
|
|
|
4
|
212010301
|
Connecting rod
|
2
|
Die-cast aluminum alloy YL104
|
|
|
5
|
212010304
|
Piston cup
|
2
|
PHB filled PTFE
|
|
|
6
|
212010302
|
Clamp
|
2
|
Die-cast aluminum alloy YL102
|
|
|
7
|
7050616
|
Screw of cross head
|
2
|
Carbon structural steel of cold heading
|
M6•16
|
|
8
|
212010501
|
Air cylinder
|
2
|
Thin wall pipe of aluninun alloy 6A02T4
|
|
|
9
|
17103
|
Seal ring of Cylinder
|
2
|
Silicone rubber
|
|
|
10
|
212010417
|
Sealing ring of cylinder cover
|
2
|
Silicone rubber
|
|
|
11
|
212010401
|
Cylinder head
|
2
|
Die-cast aluminum alloy YL102
|
|
|
12
|
7020525
|
Screw of inner hexagon Cylinder head
|
12
|
|
M5•25
|
|
13
|
17113
|
Sealing ring of connecting pipe
|
4
|
Silicong rubber
|
|
|
14
|
212010801
|
Connecting pipe
|
2
|
Aluminum and aluminum alloy connecting rod LY12
|
|
|
15
|
7100406
|
Screw of Cross head
|
4
|
1Cr13N19
|
M4•6
|
|
16
|
212010409
|
Limit block
|
2
|
Die-cast aluminum alloy YL102
|
|
|
17
|
000402.2
|
Air outlet valve
|
2
|
7Cr27 quenching steel belt of The Swedish sandvik
|
|
|
18
|
212010403
|
valve
|
2
|
Die-cast aluminum alloy YL102
|
|
|
19
|
212010404
|
Air inlet valve
|
2
|
7Cr27 quenching steel belt of The Swedish sandvik
|
|
|
20
|
212010406
|
Metal gasket
|
2
|
Stainless steel plate of heat and acidresistance
|
|
|
21
|
212010107
|
Right fan
|
1
|
Reinforced nylon 1010
|
|
|
22
|
212010201
|
Crank
|
2
|
Gray castiron H20-40
|
|
|
23
|
14040
|
Bearing 6006-2Z
|
2
|
|
|
|
24
|
70305
|
Tighten screw of inner hexagon flat end
|
2
|
|
M8•8
|
|
25
|
7020520
|
Screw of inner hexagon Cylinder head
|
2
|
|
M5•20
|
|
26
|
212010102
|
Right box
|
1
|
Die-cast aluminum alloy YL104
|
|
|
27
|
6P-4
|
Lead protective ring
|
1
|
|
|
|
28
|
70905152-211
|
Hexagon head bolt
|
2
|
Carbon structural steel of cold heading
|
M5•152
|
|
29
|
71005120-211
|
Screw of Cross head
|
2
|
Carbon structural steel of cold heading
|
M5•120
|
|
30
|
16602
|
Light spring washer
|
4
|
|
ø5
|
|
31
|
212010600
|
Stator
|
1
|
|
|
|
32
|
70305
|
Lock nut of hexagon flange faces
|
2
|
|
|
|
33
|
212010700
|
Rotor
|
1
|
|
|
|
34
|
14032
|
Bearing 6203-2Z
|
2
|
|
|
Certifications
Product packaging
FAQ
Q1: Are you factory or trade company?
A1: We are factory.
Q2: What the exactly address of your factory?
A2: Our factory is located in Linbei industrial area No.30 Ruian City of Zhejiang Province, China
Q3: Warranty terms of your machine?
A3: Two years warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: How long will you take to arrange production?
A5: Generally, 1000 pcs can be delivered within 25 days
Q6: Can you accept OEM orders?
A6: Yes, with professional design team, OEM orders are highly welcome
Q7:Can you accept non-standard customization?
A7:We have the ability to develop new products and can customize, develop and research according to your requirements
A1: We are factory.
Q2: What the exactly address of your factory?
A2: Our factory is located in Linbei industrial area No.30 Ruian City of Zhejiang Province, China
Q3: Warranty terms of your machine?
A3: Two years warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: How long will you take to arrange production?
A5: Generally, 1000 pcs can be delivered within 25 days
Q6: Can you accept OEM orders?
A6: Yes, with professional design team, OEM orders are highly welcome
Q7:Can you accept non-standard customization?
A7:We have the ability to develop new products and can customize, develop and research according to your requirements
