Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JRF
-
Model Number:
-
JRF-P5266
-
Product name:
-
ACC Panels
-
Compressive strength:
-
3.5MPa-7.0MPa
-
Dry density level:
-
B03-B08
-
Length:
-
1400-6000MM
-
Thickness:
-
50-250MM
-
Density:
-
400-650KG/M³
-
Package:
-
Non-fumigation pallet,with corner protectors on all sides
-
Size:
-
3000*600*150MM
-
Brand:
-
JRF
-
Origin:
-
China
Quick Details
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
School
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JRF
-
Model Number:
-
JRF-P5266
-
Product name:
-
ACC Panels
-
Compressive strength:
-
3.5MPa-7.0MPa
-
Dry density level:
-
B03-B08
-
Length:
-
1400-6000MM
-
Thickness:
-
50-250MM
-
Density:
-
400-650KG/M³
-
Package:
-
Non-fumigation pallet,with corner protectors on all sides
-
Size:
-
3000*600*150MM
-
Brand:
-
JRF
-
Origin:
-
China
Product Paramenters
|
Basic Performance
|
|
|
|
|
|
|||||
|
ntensity Level
|
|
A2.5
|
A3.5
|
A5.0
|
A7.5
|
|||||
|
Dry Density Level
|
|
B04
|
B05
|
B06
|
B07
|
|||||
|
Dry Density(Kg/m³)
|
|
<=425
|
<=525
|
<=625
|
<=725
|
|||||
|
Compressive Strength(MPa)
|
Average Value
|
>=2.5
|
>=3.5
|
>=5.0
|
>=7.5
|
|||||
|
|
Single Group Min
|
>=25
|
>=2.8
|
>=4.0
|
>=6.0
|
|||||
|
Drying ShrinkageValue(mm/m)
|
Standard Method
|
<=0.50
|
|
|
|
|||||
|
|
Fast Method
|
<=0.80
|
|
|
|
|||||
|
Frost Resistance
|
Mass loss(%)
|
<=5.0
|
|
|
|
|||||
|
|
Strength afterFreezing(MPa)
|
>=2.0
|
>=2.8
|
>=4.0
|
y60
|
|||||
|
Thermal Conductivity(dry)【W(m.k)】
|
|
<=0.12
|
<=0.14
|
<=0.16
|
<=0.18
|
|||||
|
|
|
|
|
|
|
Specification
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Interior Wall Panel
|
Thickness(mm)
|
50
|
75
|
100
|
125
|
150
|
175
|
200
|
250
|
|||||||||
|
|
Max Length(mm)
|
1400
|
3000
|
4000
|
5000
|
6000
|
6000
|
6000
|
6000
|
|||||||||
|
Exterior Wall Panel
|
Thickness(mm)
|
100
|
125
|
150
|
175
|
200
|
250
|
300
|
-
|
|||||||||
|
|
Max Length(mm)
|
3500
|
4500
|
5500
|
6000
|
6000
|
6000
|
6000
|
-
|
|||||||||
|
Fire Resistance of 100mm Wallboard(Hour)
|
|
|
|
>=4.0
|
|
|
|
|
|
|||||||||
|
mpact Resistance(Times)
|
|
|
|
>=15
|
|
|
|
|
|
|||||||||
|
Hanging Force(N)
|
|
|
|
>=1500
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
