* Single point connection
* Robust, efficient, and safe
* Easy and flexible installation
* 10-year limited warranty against manufacturing defects
* Two conductors
* Emits zero EMF (electromagnetic fields)
* Durable structure
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Huanrui
-
Model Number:
-
HM-08
-
Product name:
-
Driveway heating snow melt heating cable snow melting mats
-
Insulation:
-
Fluoropolymer and XLPE
-
Shield:
-
Al foil + Cu wire
-
Outer jacket:
-
PVC
-
Outside diameter:
-
6.5mm
-
Rated voltage:
-
230V, 400V
-
Output wattage:
-
30W/m
-
Max. rated Temp:
-
105℃
-
Min. installation Temp:
-
5℃
-
Cold lead:
-
6m length
Quick Details
-
Warranty:
-
2 years
-
After-sale Service:
-
Online technical support, Return and Replacement, Other
-
Project Solution Capability:
-
total solution for projects, Others
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Huanrui
-
Model Number:
-
HM-08
-
Product name:
-
Driveway heating snow melt heating cable snow melting mats
-
Insulation:
-
Fluoropolymer and XLPE
-
Shield:
-
Al foil + Cu wire
-
Outer jacket:
-
PVC
-
Outside diameter:
-
6.5mm
-
Rated voltage:
-
230V, 400V
-
Output wattage:
-
30W/m
-
Max. rated Temp:
-
105℃
-
Min. installation Temp:
-
5℃
-
Cold lead:
-
6m length
Product Description
Features
Introduction
The HM-Mat is an electrically heated
Mat
designed to prevent snow and ice accumulation around the home or facility, such as driveway, walkways and stairs and so on.
In winter, when the accumulated snow on walkways, parking garage, loading ramps, stairways and other areas, it will bring problem to people’s life. Electric snow melting systems can keep walkways, parking garage, loading ramps, stairways and other areas free of snow and ice to help prevent slip hazards. Electric snow melting systems provide surface snow melting and anti-icing for concrete surfaces and pavers.
In winter, when the accumulated snow on walkways, parking garage, loading ramps, stairways and other areas, it will bring problem to people’s life. Electric snow melting systems can keep walkways, parking garage, loading ramps, stairways and other areas free of snow and ice to help prevent slip hazards. Electric snow melting systems provide surface snow melting and anti-icing for concrete surfaces and pavers.
Technical Data
Cable structure Twin conductor
Rated voltage 230V, 400V
Power output 30W/m
Heating element length 10m to 120m
Bending radius 38mm
Outer diameter 6.5mm
Outer jacket material PVC
Jacket optional XLPO for HM-cable(R)
Insulation Fluoropolymer and XLPE
Shield Aluminum-plastic tape and tinned copper wires
Max. rated temperature 105°C
Min. installation temperature 5°C
Cold lead 6m length and required
Certification CE
Applications
Install the HM-mat snow melting system provides a permanent solution to the problems caused by cold weather when snow and ice accumulation. It can be used both outdoor and indoor environment.
* Ideal for driveways,parking lots,sidewalks,stairs,ramps,bridges and many other applications.
* For used under concrete,asphalt,paver or stone and ceramic or stone tile
* Roof &gutter de-icing
* subfloor energy storage heating.
* Ideal for driveways,parking lots,sidewalks,stairs,ramps,bridges and many other applications.
* For used under concrete,asphalt,paver or stone and ceramic or stone tile
* Roof &gutter de-icing
* subfloor energy storage heating.
Details Images
|
Item
|
Driveway heating snow melt heating cable snow melting mats
|
|
Sample
|
Free samples are available
|
|
MOQ
|
200 meters
|
|
OEM and ODM
|
Available
|
|
OEM service
|
Cable color, cable printing, color boxs. Any other requirements, please contact us.
|
|
Delivery time
|
Usually within 15 days, large orders and OEM orders should be negotiated.
|
Product Paramenters
|
Part Number
|
Heating Area/
㎡
|
Mat size/m*m
|
power output/w
|
|
HM-mat-300-1.0
|
1.0
|
0.6*1.7
|
300
|
|
HM-mat-300-1.5
|
1.5
|
0.6*2.5
|
450
|
|
HM-mat-300-2.0
|
2.0
|
0.6*3.3
|
600
|
|
HM-mat-300-2.5
|
2.5
|
0.6*4.2
|
750
|
|
HM-mat-300-3.0
|
3.0
|
0.6*5.0
|
900
|
|
HM-mat-300-3.5
|
3.5
|
0.6*5.8
|
1050
|
|
HM-mat-300-4.0
|
4.0
|
0.6*6.7
|
1200
|
|
HM-mat-300-4.5
|
4.5
|
0.6*7.5
|
1350
|
|
HM-mat-300-5.0
|
5.0
|
0.6*8.3
|
1500
|
|
HM-mat-300-6.0
|
6.0
|
0.6*10.0
|
1800
|
|
HM-mat-300-7.0
|
7.0
|
0.6*11.7
|
2100
|
|
HM-mat-300-8.0
|
8.0
|
0.6*13.3
|
2400
|
|
HM-mat-300-9.0
|
9.0
|
0.6*15
|
2700
|
|
HM-mat-300-10.0
|
10.0
|
0.6*16.7
|
3000
|
|
HM-mat-300-12.0
|
12.0
|
0.6*20
|
3600
|
Packaging and Shipping
