Quick Details
-
Model Number:
-
XEL-S-MAP
-
Protection Level:
-
IP67
-
Operating Temperature:
-
-20-60℃
-
Max. Current:
-
3A
-
Rating Load:
-
3A 240VAC, 3A 30VDC
-
Contact:
-
Golden plated silver contact
-
Housing Material:
-
Reinforced plastic shell
-
Contact Forms:
-
1NC+1NC
-
Outlet Hole cable gland:
-
M20, PG13.5
-
Brand:
-
XURUI
-
Electrical Life:
-
100,000 times above
-
Mechanical Life:
-
1,000,000 times above
-
Standard:
-
EN60947-5-1
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
240VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
xurui
-
Model Number:
-
XEL-S-MAP
-
Protection Level:
-
IP67
-
Operating Temperature:
-
-20-60℃
-
Max. Current:
-
3A
-
Rating Load:
-
3A 240VAC, 3A 30VDC
-
Contact:
-
Golden plated silver contact
-
Housing Material:
-
Reinforced plastic shell
-
Contact Forms:
-
1NC+1NC
-
Outlet Hole cable gland:
-
M20, PG13.5
-
Brand:
-
XURUI
-
Electrical Life:
-
100,000 times above
-
Mechanical Life:
-
1,000,000 times above
-
Standard:
-
EN60947-5-1
-
Certification:
-
CE
XURUI Mechanical locking safety door switch 1NC1NC 3A 240VAC IP67 with key for emergency
Features:
1.Reinforced plastic shell, oil-proof, and waterproof.
2.Multiple sets of gold-plated silver contact combination,flexible configuration.
3.High Locking force,up to 1300n.
4.The indicator light indicatses the working status,configure the emergency unlock function.
5. Equipped with 6 types operation keys.
6.Opening and protection devices for safety doors in the industrial field
.
