Quick Details
Quick Details
| 2 stroke 4 stroke boat engine outboard motor | |
| Requirement parameter | Engine Type |
| Idle speed | |
| Displacement | |
| Bore*Stroke | |
| Max.Power Output | |
| Gear Ratio | |
| Transom height | |
| Fuel tank | |
| Cylinder number | |
| Usage | |
2 stroke Engines 15HP Short Shaft Boat outboard motor CE approved
| H.P. | 15HP | 15HP |
| (mm/in)OVERALL LENGTH | 873(34.4) | 873(34.4) |
| (mm/in)OVERALL WIDTH | 330(13.0) | 330(13.0) |
| (mm/in)OVERALL HEIGH | 1167(45.9) | 1167(45.9) |
| (mm/in)TRANSOM HEIGH | 567(22.3) | 567(22.3) |
| ENGINE TYPE | 2 stroke | 2 stroke |
| DISPLACEMENT(cc) | 246 | 246 |
| BORE*STROKE(mm) | 56*50 | 56*50 |
| MAX. OUTPUT(hp/kw) | 11(15) | 11(15) |
| RPM | 4500-5500 | 4500-5500 |
| STARTING SYSTEM | MANUAL | MANUAL |
| IDLING SPEED(IN NEUTRAL) | 700-800 | 700-800 |
| TRIM METHOD | MANUAL | MANUAL |
| IGNITION SYSTEM | CDI | CDI |
| CONTROL SYSTEM | TILLER | TILLER |
| GEAR POSITIONS | Forward-neutral-reverse | Forward-neutral-reverse |
| PROPELLER(in) | 3*9 1/4"*8" | 3*9 1/4"*8" |
| Integral fuel tank capacity(L) | \ | \ |
| Separate fuel tank capacity(L) | 24 | 24 |
| WEIGHT(KG) | 37.5 | 37.5 |
| Fuel :Oil RATIO | 50:1 | 50:1 |
| PACKED CASE SIZE(cm) | 134.5*80*51 | 134.5*80*51 |
| CONTAINER LOADING(20GP/40HQ) | 60/150 | 60/150 |
