Quick Details
-
Weight (KG):
-
252
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WELIN
-
Dimension(L*W*H):
-
1330*1040*1420mm
-
Product name:
-
Big Large Heavy Duty Mini Doypack Pouch Packing Machine
-
Building Material:
-
304SUS material, anodized aluminium profiles
-
Usage:
-
liquid, powder, small granules, pet food, metal parts
-
Station:
-
Single head station pick up-open- fill-seal
-
Pouch Width:
-
120-450mm
-
Pouch Length:
-
120-500mm
-
Max. Speed:
-
5-10 BPM
-
Control Panel:
-
7" User's friendly Touch Screen
-
Driven system:
-
Pnematical Driven
-
Pouch type:
-
Big Large Heavy Duty PE Aluminum Laminated premade pouch
Quick Details
-
Function:
-
FILLING, Sealing, big large heavy duty pouch open fill seal
-
Packaging Type:
-
Bags, Pouch, Stand-up Pouch, big large heavy duty pre-made pouch
-
Packaging Material:
-
Plastic, Paper
-
Weight (KG):
-
252
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WELIN
-
Dimension(L*W*H):
-
1330*1040*1420mm
-
Product name:
-
Big Large Heavy Duty Mini Doypack Pouch Packing Machine
-
Building Material:
-
304SUS material, anodized aluminium profiles
-
Usage:
-
liquid, powder, small granules, pet food, metal parts
-
Station:
-
Single head station pick up-open- fill-seal
-
Pouch Width:
-
120-450mm
-
Pouch Length:
-
120-500mm
-
Max. Speed:
-
5-10 BPM
-
Control Panel:
-
7" User's friendly Touch Screen
-
Driven system:
-
Pnematical Driven
-
Pouch type:
-
Big Large Heavy Duty PE Aluminum Laminated premade pouch
Product Overview
WL-MDP450 MINI DOYPACK PACKING MACHINE
(BIG/LARGE/HEAVY DUTY PREMADE POUCH LOAD OPEN FILL SEAL)
This mini doypack packing machine delivers automation premade big large heavy duty pouch load pickup open fill seal, which can be used for various preformed bags, such as three side seal bags, stand-up bags, ziplock bags, gusset bags, etc. to complete automatic bag pick-up, bag open, fill, seal and finished product output. It is suitable for all kinds of food packaging, such as coffee, frozen food, biscuits, Cereals, nuts, powdered materials, candy, etc. It can be used with screw scale, linear scale, combined scale and other filling equipment.
FEATURES AT A GLANCE
New generation sanitary design & build
Easy clean and avoid trash accumulated.
Compact footprint & Low Maintenance
Compact single station, pneumatic system used for safety running & low maitenance.
Auto Operation Control
From pouch pick up-open-fill-seal to output which is controlled by PLC
7" User's friendly H.M.I. ensure high efficiency performance.
Easy to Adjust & Operate
No Pouch, No Dump
Interlock Safety, CE Application - auto stop when the door is open,
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
|
Model
|
WL-MDP450
|
|
Pouch Types
|
Big Heavy Duty Large PE Laminated Aluminum
3-side seal, zip-lock, gusset, stand-up
|
|
Pouch Size
|
250-450mm(W) *250-500mm(L)
|
|
Speed
|
5-8BPM
|
|
Power
|
220V/50HZ, 60HZ 1P 1KW
|
|
Air Consumption
|
7.0 CFM@80 PSI
|
|
Control Panel
|
7 inches Touch Screen
|
|
Packing Size
|
1330*1040*1420mm, 252kg
|
|
Options
|
Auto Ziplock Opener
Big Pouch holding device Date Printer Output Conveyor Different Weight Filler |
More About Weighlin
Established in 2011, WEIGHLIN dedicated in food weighing packaging machines, included high speed high precision multihead weighers, economical practical linear weighers, dynamic weight checking and grading, performed pouches packing machine, high quality accessories such as platform and conveyors, also full feeding weighing packaging inspecting line, etc and other related customized packaging machines. Quality packaging solution is from Weighlin years of focus and understanding of the packaging industry. WEIGHLIN strives for perfection in the pursuit of quality, while taking into account easy to operate, easy to disassemble, easy to clean, small investment, stable performance, so that the packaging carry, deliver and create value.
FAQ About Weighlin
A. What is Weighlin's motto about packaging?
Packaging carry deliver and create Value.
B. When Weighlin started and what's your main products?
Weighlin is established in 2011 and there are more than 10 years background R&D and salesman staffs with professional knowledge.
Our main products are included new generation modular control linear weigher, multihead weigher, checkweigher and metal detector, mini premade pouch packing machine and mini VFFS, and complete turnkey packing line solution as well.
C. Why choose Weighlin packaging?
1. Competitive Price. As a original manufacturer, we have our own modern workshop processing facility from laser, folding and welding machining, experienced staff and quality control system, we can control good quality and cost by ourself.
2. Prompt Response. Well-trained and know-how salesteam, working 24/7 to make reaction to the inquiries and questions all the time within 12 hours.
3. On time delivery. The products ordered are always delivered on time,which not only helps in saving time but also cost for our customers.The timely delivery enssures our customers to inspect the products well before there proper usages. We also value our punctuality and offer our customers trouble free products.
4. Honesty and professionalism marketing policy. We always stand by your side. We are dedicated to give our customers the best services possible with complete honesty. Professionalism to the complete satisfaction of our customers.
5. Low Maintenance. The products delivered according to our customers requirements not only excellent in quality but also prove to be of low maintenance.
6. Parts and accessories storage. we have well stocked parts and accessories for each and every machinery.
7. Flexible custom ODM ability and 7*24hours aging testing before shipment.
D. What's Weighlin service support?
Pre-Sales Service (Inquiry and consulting support. Sample testing support. View our Factory)
Mid-Sales Service (Update the production progress with photo and video, Material or pouch testing running)
After-Sales Service (Installation training, Operation training; Engineers are available to service overseas)
