Quick Details
-
Brand Name:
-
agro-helper
-
Product name:
-
Laser Grader
-
Working width (mm):
-
2500
-
Supporting Power (kw):
-
55-65
-
Wheelbase (mm):
-
1790
-
The radiation diameter(m):
-
500
-
Certification:
-
EPA
Quick Details
-
Weight (KG):
-
700
-
Marketing Type:
-
Hot Product 2022
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
agro-helper
-
Product name:
-
Laser Grader
-
Working width (mm):
-
2500
-
Supporting Power (kw):
-
55-65
-
Wheelbase (mm):
-
1790
-
The radiation diameter(m):
-
500
-
Certification:
-
EPA
Product Description
|
Model
|
1JP-200
|
1JP-250
|
1JP-300
|
1JP-350
|
|
Working width (mm)
|
2000
|
2500
|
3000
|
3500
|
|
Supporting Power (KW)
|
40-55
|
55-65
|
65-80
|
80-120
|
|
Operating efficiency (km/h)
|
1.0-1.3
|
1.3-1.8
|
1.6-2.0
|
1.9-2.3
|
|
Operating speed (km/h)
|
5-15
|
5-15
|
5-15
|
5-15
|
|
Working stroke (mm)
|
500
|
500
|
500
|
500
|
|
Depth of entry (mm)
|
240
|
240
|
240
|
240
|
|
Transmitter/receiver model
|
Rugby410/GL3000
|
Rugby410/GL3000
|
Rugby410/GL3000
|
Rugby410/GL3000
|
|
Operating voltage of controller (V)
|
11-30DC
|
11-30DC
|
11-30DC
|
11-30DC
|
|
Automatic leveling Angle (0)
|
±5
|
±5
|
±5
|
±5
|
|
Flatness (mm)
|
±15
|
±15
|
±15
|
±15
|
|
Lifting speed of scraper (mm/s)
|
Up >, 50 down b>, 60
|
Up >, 50 down b>, 60
|
Up >, 50 down b>, 60
|
Up >, 50 down b>, 60
|
|
Wheelbase (mm)
|
1590
|
1790
|
1990
|
2190
|
|
Tillage range (mm)
|
200
|
250
|
300
|
350
|
|
Radiation diameter (m)
|
500
|
500
|
500
|
500
|
|
Work efficiency (mu/hour)
|
2-3
|
2-4
|
2-5
|
2-7
|
|
Depth of shovel (mm)
|
20-50
|
20-50
|
20-50
|
20-50
|
|
Overall dimension (length * width * height)
|
3*2.25*3.65
|
3*2.65*3.65
|
3*3.05*3.65
|
3*3.55*1.5
|
|
Machine weight (kg)
|
700
|
800
|
1000
|
1500
|
