Quick Details
-
Oiled or Non-oiled:
-
Slightly Oiled
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
Jiangsu, China
-
Outer Diameter:
-
2 - 60 mm
-
Grade:
-
Carbon
-
Delivery condition:
-
NBK,+N
-
Material:
-
Carbon Steel
-
Secondary Or Not:
-
Non-secondary
Quick Details
-
Section Shape:
-
Round
-
Surface Treatment:
-
copper-plated, zinc-coated, without smooth coating
-
Tolerance:
-
±5%
-
Oiled or Non-oiled:
-
Slightly Oiled
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
Jiangsu, China
-
Outer Diameter:
-
2 - 60 mm
-
Grade:
-
Carbon
-
Delivery condition:
-
NBK,+N
-
Material:
-
Carbon Steel
-
Secondary Or Not:
-
Non-secondary
Product Description
Standard
|
Dimension
|
|
|
|
OD(mm)
|
WT(mm)
|
|
|
4
|
0.5
|
|
|
4.76
|
0.6
|
|
|
4.76
|
0.65
|
|
|
6
|
0.6
|
|
|
6
|
0.65
|
|
|
8
|
0.6
|
|
|
OD<8mm, use hot dipped galvanizedOD ≥ 8mm, use eletronic zinc coating(galvanizing)
|
|
|
|
Dimension check
|
|
Tolerance on
Outer Diameter(mm) +0.03mm -0.03mm |
||
|
|
|
Tolerance on
Wall Thickness(mm) +0.03mm -0.01mm |
||
|
Seal Airtight Test
|
|
1.6Mpa N2,without leaking
|
||
|
Inside Surface Cleanliness
(soluble residue) (insoluble residue) |
|
<50mg/m²
|
||
|
MECHANICAL
COMPOSITION(%) |
TENSILE
Rm(N/mm2) |
≥270
|
||
|
|
YIELD
Rel(N/mm2) |
≥180
|
||
|
|
ELONGATION
A |
(%)≥14
|
||
|
CHEMEICAL COMPOSITION(%)
|
C
|
≤0.11%
|
||
|
|
Mn
|
≤0.4%
|
||
|
|
S
|
≤0.03%
|
||
|
|
P
|
≤0.03%
|
||
|
Surface treatment:
copper-plated, zinc-coated, without smooth coating |
|
|
||
Manufacture Process:
