Quick Details
-
Cabinet material:
-
SS304
-
Arm material:
-
SS304 or Acrylic
-
Arm length:
-
500mm to 800mm
-
Direction:
-
single or bi-direction
-
Open arm in emergency:
-
Yes
-
Package:
-
Carton or Wooden Box
-
Certificates:
-
CE
-
Warranty:
-
One Year
-
Application:
-
Indoor/outdoor with tent
-
Control input:
-
dry contact/relay signal
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SINOMATIC
-
Model Number:
-
SN-ISB10
-
Cabinet material:
-
SS304
-
Arm material:
-
SS304 or Acrylic
-
Arm length:
-
500mm to 800mm
-
Direction:
-
single or bi-direction
-
Open arm in emergency:
-
Yes
-
Package:
-
Carton or Wooden Box
-
Certificates:
-
CE
-
Warranty:
-
One Year
-
Application:
-
Indoor/outdoor with tent
-
Control input:
-
dry contact/relay signal
Functions & Features
1) Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card.
2) DC Brushless Motor, Maintenance Free
3) On-line or off –line mode(optional)
4) Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent force passing without the card
7) Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000
8) Light and sound alarm indication function, preventing illegal entry or irregular passing
9) Powerful on-line intelligent control mode, facilitating you
A) To adjust the operation speed of the barrier according to the flow of passenger and improve the passing rate.
B) To set up operation mode for passage entry and exit.
C) To read card with multiple times, the special function meeting the application requirements of a particular site.
D) To set up the card reading with or without memory.
E) To select a reasonable normally open or close mode, to divert the flow of passengers effectively.
F) Setting function humanized for reset of over time passing.
2) DC Brushless Motor, Maintenance Free
3) On-line or off –line mode(optional)
4) Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent force passing without the card
7) Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000
8) Light and sound alarm indication function, preventing illegal entry or irregular passing
9) Powerful on-line intelligent control mode, facilitating you
A) To adjust the operation speed of the barrier according to the flow of passenger and improve the passing rate.
B) To set up operation mode for passage entry and exit.
C) To read card with multiple times, the special function meeting the application requirements of a particular site.
D) To set up the card reading with or without memory.
E) To select a reasonable normally open or close mode, to divert the flow of passengers effectively.
F) Setting function humanized for reset of over time passing.
11) The infrared sensing technique realizes real time monitor of passage, safe protection and tail-proof.(This model not inlucde sensor)
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration of the system and the other equipment, to realize far end
control management.
14) Super combination capability, with the combined application of products of different passage types and series, not affecting the system performance.
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration of the system and the other equipment, to realize far end
control management.
14) Super combination capability, with the combined application of products of different passage types and series, not affecting the system performance.
Product Specs
|
Power supply
|
AC100V~240V, DC24V
|
|
Power consumption
|
140W
|
|
Access device input voltage
|
Dry contact or 12V electrical level signal or > 100ms 12V impulse signal,
driving current > 10mA
|
|
Max flow rate
|
30 person per minute
|
|
Arm length
|
400mm to 900mm
|
|
Working temperature
|
-20°C~+60°C
|
|
Current
|
3A
|
|
Control circuit
|
DC24
|
|
Working humidity
|
0~95%RH
|
|
Time of opening or closing
|
less than 2s
|
Product size
Production line
Cases reference
Related products
Our Company
Shenzhen Sinomatic Technology Co., Limited always focus on the manufacturing of access control turnstile and barrier for high security with the customers' encouragements and supports.
Main products includes pedestrian control turnstiles, parking barriers and parking locks, road blockers and road bollards etc.
Products has been exported to all over the world, favored by the majority of the customers. High quality and good faith for customers is our pricinple and this is also our biggest motivation.
Main products includes pedestrian control turnstiles, parking barriers and parking locks, road blockers and road bollards etc.
Products has been exported to all over the world, favored by the majority of the customers. High quality and good faith for customers is our pricinple and this is also our biggest motivation.
