Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Weho
-
Voltage:
-
380V/50HZ
-
Weight (KG):
-
6000 KG
-
Power (kW):
-
4
-
Dimension(L*W*H):
-
3750*1700*2100mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Usage:
-
hot pressing machine
-
Functions:
-
woodworking hot press
-
Dimension of Hot Platens:
-
1300*2500mm or customized
-
Hot press pressure:
-
80-500Tons
-
Application:
-
Wood door furnitures board
-
heating pipe power:
-
54kw
-
Max platen opening:
-
300mm
-
Product aim:
-
woodworking veneer lamilating
-
Net weight:
-
6000kg
Quick Details
-
Max.Pressure(T):
-
500 T
-
Working Table Size(mm):
-
1300*2500
-
Pressure:
-
100T
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Weho
-
Voltage:
-
380V/50HZ
-
Weight (KG):
-
6000 KG
-
Power (kW):
-
4
-
Dimension(L*W*H):
-
3750*1700*2100mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Usage:
-
hot pressing machine
-
Functions:
-
woodworking hot press
-
Dimension of Hot Platens:
-
1300*2500mm or customized
-
Hot press pressure:
-
80-500Tons
-
Application:
-
Wood door furnitures board
-
heating pipe power:
-
54kw
-
Max platen opening:
-
300mm
-
Product aim:
-
woodworking veneer lamilating
-
Net weight:
-
6000kg
Woodworking hydraulic hot pressing machine MH3848*100T
Widely used in laminating veneer face,melamine for MDF board,plywood
and other fibreboard,etc.;
high-speed double-face laminating,easy to operate and maintain
It’s the best choice in making veneer sheets and laminated flooring;
Professional design,secure and reliable;
Adopt high quality and power brand accessories,as to the main components
and parts as well as all the hydraulic components.
|
Model |
MH3848 |
|
Press platen dimensions |
1300*2500*42mm |
|
Max. total thrust |
100-500T |
|
Pressure of hydraulic |
295kg/ cm2 |
|
Max. platen opening |
100mm/80mm |
|
Oil cylinder |
85*8pcs |
|
Hydraulic motor |
7.5kw |
|
Hot oil pump |
2.2kw |
|
Heating pipe power |
72kw |
|
Overall size |
3700*1660*2650mm |
|
N/W |
7900kg |
hot pressing machine for pressing veneer ,fireproofing-board ,decorating-paper and so on.
Come with solid steel heat plate board which have deep-hole drilling technic ,configure with pedal emergency switch ,quadric temperature protection device etc;
Hydraulic parts cylinders and composites are imported from Japan and Taiwan .
Heating type :
1.Electric heating with circulating heat-transmission oil (standard configuration );
2.Steam heating (optional)
3.With both electric and steam hearing ,suitable for shortage of steam area
High quality column cylinder, famous brand in China.
Safe cover with woodworking hot press is standard parts.
Origianl Taiwan Yutiea hydraulic system and hydraulic valve, strong and durable.
7.5KW 10HP motor for lift table, fast open hot platen.
Manufacturing hydraulic hot pressing machine from 15 years ago, full production experience for speical requirement.
Contact us for more information.
