Quick Details
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
China
-
Brand Name:
-
MX/OEM/ODM
-
Model Number:
-
MX12038ZBL1
-
Voltage:
-
DC 12V/24V/48V
-
Product name:
-
DC Brussless Fan
-
Size:
-
120x120x38mm
-
Speed:
-
3000-4500RPM
-
Application:
-
Exhaust Ventilation
-
Usage:
-
Industry Greenhouse
-
Keyword:
-
Exhaust Cooling Fan
-
Motor:
-
Copper Motor
-
Bearing Type:
-
Ball
-
Name:
-
Industrial Axial Flow Ventilation Exhaust Fan
-
sample:
-
Free
Quick Details
-
Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
-
Electric Current Type:
-
DC
-
Mounting:
-
Roof Fan
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
China
-
Brand Name:
-
MX/OEM/ODM
-
Model Number:
-
MX12038ZBL1
-
Voltage:
-
DC 12V/24V/48V
-
Product name:
-
DC Brussless Fan
-
Size:
-
120x120x38mm
-
Speed:
-
3000-4500RPM
-
Application:
-
Exhaust Ventilation
-
Usage:
-
Industry Greenhouse
-
Keyword:
-
Exhaust Cooling Fan
-
Motor:
-
Copper Motor
-
Bearing Type:
-
Ball
-
Name:
-
Industrial Axial Flow Ventilation Exhaust Fan
-
sample:
-
Free
Product Details
Ventilation Fan dc ac ec pwm high CFM silent ventilators for solar roof ventilation bath room exhaust dusting Axial Flow Fans
OEM ODM
service
We can provide free samples before you order in bulk.
|
Model
|
Bearing
Type
|
Rated Volt
|
Operating Volt
|
Rated Current
|
Input Power
|
Speed
|
Max. Airflow
|
Max. Static Pressure
|
Noise Level
|
||||||||
|
Part No.
|
S B Y
|
VDC
|
VDC
|
AMP
|
Watt
|
RPM
|
CFM
|
Pa
|
dB-A
|
||||||||
|
MX12038ZBU2
|
B
|
24
|
13.8-26.8
|
2
|
48
|
4500
|
222.3
|
215.3
|
64
|
||||||||
|
MX12038ZBH2
|
B
|
24
|
13.8-26.8
|
1
|
24
|
4000
|
193.5
|
167.7
|
60
|
||||||||
|
MX12038ZBM2
|
B
|
24
|
13.8-26.8
|
0.7
|
16.8
|
3500
|
173.3
|
134.4
|
55
|
||||||||
|
MX12038ZBL2
|
B
|
24
|
13.8-26.8
|
0.5
|
12
|
3000
|
146
|
97.8
|
50
|
||||||||
|
More Models
|
Other RPM/CFM/Voltage/Current...please contact us see the specification for more details.
|
|
|
|
|
|
|
|
|
||||||||
Product Breakdown
|
Product Name
|
DC Axial Fan
|
|
Brand
|
MX topfan/OEM/ODM
|
|
Frame and Impeller
|
Metal & Plastic(94V-0)，PBT
|
|
Bearing Type
|
Sleeve bearing&Ball Bearing
|
|
Function Range
|
PWM FG RD IP58 IP68
|
|
Leadwire
|
Red Wire Positive(+)，Black Wire Negative(-)
|
|
Rated Voltage
|
5V 12V 24V 48V 110v 220v 230v 380v ...
|
|
Operating Tempetature
|
-30℃ to +80℃
|
|
Product Applications
|
Household Appliances/Machine/Aeronautical/Power equipment, etc
|
