Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Allraise
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
2700x1140x1860mm
-
Weight:
-
1140 kg
-
Warranty:
-
1year
-
After-sales Service Provided:
-
Overseas third-party support available
-
Item:
-
Beer label die cutting machine/hydraulic die cutter
-
Max. Cutting Size:
-
340x340mm
-
Min. Cutting Size:
-
150x150mm
-
Cutting Stroke:
-
200mm
-
Applicable material:
-
playing cards, aluminum plastic, PP, PE-foil
-
Max die cutting speed:
-
12000 sheets/min
-
Max Die Cutting Pressure:
-
50KN
-
Function:
-
Cutting paper, pvc card, self-adhesive foil, envelopes
-
Dimension:
-
2700x1140x1860mm
Quick Details
-
Type:
-
Die-cutting Machine
-
Production Capacity:
-
Other
-
Max. workable width:
-
Other
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Allraise
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
2700x1140x1860mm
-
Weight:
-
1140 kg
-
Warranty:
-
1year
-
After-sales Service Provided:
-
Overseas third-party support available
-
Item:
-
Beer label die cutting machine/hydraulic die cutter
-
Max. Cutting Size:
-
340x340mm
-
Min. Cutting Size:
-
150x150mm
-
Cutting Stroke:
-
200mm
-
Applicable material:
-
playing cards, aluminum plastic, PP, PE-foil
-
Max die cutting speed:
-
12000 sheets/min
-
Max Die Cutting Pressure:
-
50KN
-
Function:
-
Cutting paper, pvc card, self-adhesive foil, envelopes
-
Dimension:
-
2700x1140x1860mm
Trademark die cutting machine/hydraulic die cutter
Description of Trademark die cutting machine/hydraulic die cutter
LPM Series punching machine is mainly product of our company.
It is Suitable for the production of labels, playing cards, aluminum plastic, PP ,PE-foil, self-adhesive foil, envelopes of any design or size.with an average production of about 900.000 production of high precision hourly.
This machine adopts hydraulic pressure system.
with a push-cubeself-adjusting to every position of the"V"holdwhere the pack is positioned
the working table has a photoelectric cell which gives maximum safety to the operator and allows
a quick change of the follow punch and is adaptable both forlow and medium production.
The working process is completely stability.The die cutting products surface is smooth, and the size is unified and regular with high precision.
Parameters of Trademark die cutting machine/hydraulic die cutter
|
Model |
LPM-150 |
LPM-220 |
LPM-280 |
LPM-400 |
LPM-500 |
|
Max. cutting size |
100x100mm |
150x150mm |
190x190mm |
270x270mm |
340x340mm |
|
Min. cutting size |
55x40mm |
55x40mm |
90x70mm |
120x120mm |
150x150mm |
|
Cutting stroke |
200mm |
200mm |
200mm |
200mm |
200mm |
|
Nominal force |
16KN |
30KN |
40KN |
50KN |
50KN |
|
Working speed |
12000 sheets per min |
||||
|
Motor power |
1.5kw |
2kw |
3kw |
4kw |
4kw |
|
Net Weight |
300kg |
360kg |
560kg |
900kg |
1140kg |
Features of Trademark die cutting machine/hydraulic die cutter
1. Widely use: It is Suitable for the production of labels, playing cards, aluminum plastic, New year card, notebook, envelopes of any design or size.
2. High efficiency: with an average production of about 900.000 production of high precision hourly.
3. This machine adopts hydraulic pressure system.
4. With a push-cube self-adjusting to every position of the "V" hold where the pack is positioned
5. the working table has a photoelectric cell which gives maximum safety to the operator and allows
6. The working process stability, products surface is smooth, and the size is unified and regular with high precision
We have work videos of this machine for you reference,please contact me if any interests!
Similar products
Packing&Delivery of Trademark die cutting machine/hydraulic die cutter
| Payment terms: | TT, L/C at sight,Western Unit |
| Sample lead-time: |
3-7days after receive the sample charge |
| Delivery time: | 3-10 days after order confirmed |
| Freight term: | FOB,C&F,CIF ect. or by air |
| Port: | main port in china mainland |
