- Product Details
- {{item.text}}
Quick Details
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
Far-go
-
Model Number:
-
HDP5000
-
Place of Origin:
-
Japan
-
Printing Method:
-
HDP Dye-Sublimation / Resin Thermal Transfer
-
Max Card Size:
-
CR 79 & CR 80
-
Print only:
-
030" (30 mil) to .050" (50 mil) / 762mm to 1.27mm
-
Features:
-
600DPI resolution
-
Lam Module:
-
12.75"H x 12.25"W x 9.25"D / 324mmH x 313mmW x 235mmD
-
Supply Voltage:
-
50 Hz / 60 Hz
-
printer option:
-
single side or dual side with lamination
-
Input Card Cartridge Capacity:
-
100 cards (.030" / .762mm)
-
Output Hopper Card Capacity:
-
200 cards (.030" / .762mm)
-
Product name:
-
HDP5000
-
Style:
-
Color
-
Use:
-
Card Printer
-
Type:
-
retransfer
Quick Details
-
Max Paper Size:
-
CR80
-
Black Print Speed:
-
Up to 35 seconds per card / 102 cards per hour
-
Color Print Speed:
-
Up to 48 seconds per card / 75 cards per hour
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
Far-go
-
Model Number:
-
HDP5000
-
Place of Origin:
-
Japan
-
Printing Method:
-
HDP Dye-Sublimation / Resin Thermal Transfer
-
Max Card Size:
-
CR 79 & CR 80
-
Print only:
-
030" (30 mil) to .050" (50 mil) / 762mm to 1.27mm
-
Features:
-
600DPI resolution
-
Lam Module:
-
12.75"H x 12.25"W x 9.25"D / 324mmH x 313mmW x 235mmD
-
Supply Voltage:
-
50 Hz / 60 Hz
-
printer option:
-
single side or dual side with lamination
-
Input Card Cartridge Capacity:
-
100 cards (.030" / .762mm)
-
Output Hopper Card Capacity:
-
200 cards (.030" / .762mm)
-
Product name:
-
HDP5000
-
Style:
-
Color
-
Use:
-
Card Printer
-
Type:
-
retransfer
Product Description
|
Print Method
|
HDP Dye-Sublimation / Resin Thermal Transfer
|
|
Resolution
|
300 dpi (11.8 dots/mm)
|
|
Colors
|
Up to 16.7 million / 256 shades per pixel
|
|
Print Ribbon Options
|
• Full-color, YMC*, 750 prints
• Full-color with resin black, YMCK*, 500 prints
• Full-color with two resin black panels, YMCKK*,500 prints,
• Full-color with resin black and heat seal panel for difficult-to-print surfaces, YMCKH*, 500 prints
• Full-color with resin black and inhibit panel for signature or other non-printing areas, YMCKI*, 500 prints
• Full-color with fluorescing and resin black, YMCFK*, 500 prints
• Resin black, K, 3000 prints
|
|
HDP Film Options
|
• Clear (1,500 prints)
• Standard Holographic (500 prints)
• Custom Holographic, special order (500 prints)
|
|
Print Speed
|
Up to 24 seconds per card / 150 cards per hour (YMC with transfer)*
• Up to 29 seconds per card / 124 cards per hour (YMCK with
transfer)*
• Up to 40 seconds per card / 90 cards per hour (YMCKK with transfer)*
• Up to 35 seconds per card / 102 cards per hour
(YMCK with transfer and dual-sided, simultaneous lamination)
• Up to 48 seconds per card / 75 cards per hour
(YMCKK with transfer and dual-sided, simultaneous lamination)
|
|
Card Cleaning
|
Replaceable cleaning roller (included with each print ribbon)
|
|
Dimensions
|
• HDP5000: 11.50”H x 12.25”W x 9.25”D / 292mmH x 313mmW x 235mmD
• HDP5000 + Dual-Sided Module: 11.50”H x 17.50”W x 9.25”D /
292mmH x 445mmW x 235mmD
• HDP5000 + Single-Sided Lam Module: 12.75”H x 25”W x 9.25”D / 324mmH x 635mmW x 235mmD • HDP5000 +
Dual-Sided Module + Dual-Sided Lam Module: 12.75”H x 30”W x 9.25”D / 324mmH x 762mmW x 235mmD
• Lam Module: 12.75”H x 12.25”W x9.25”D / 324mmH x 313mmW x 235mmD
|
|
Weight
|
• HDP5000: 16 lbs. / 7.3 kg, HDP5000 + Dual-Sided Module: 22 lbs. / 10 kg, HDP5000 + Single-Sided Lam Module: 28 lbs. / 12.7 kg,
•HDP5000 + Dual-Sided Module + Dual-Sided Lam Module: 36 lbs. / 16.4 kg
|
|
|
|
Packing & Delivery
1set in Original package
