Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XINOUHUA
-
Model Number:
-
PA81000
-
Output Frequency:
-
50HZ/60HZ
-
Output Current:
-
0-200A
-
working temperature:
-
0-45
-
Size:
-
370*480*150
-
Protection:
-
Overvoltage
-
operating humidity:
-
10-90
-
efficiency:
-
90%
-
Warranty:
-
1 Year
-
Output waveform:
-
Pure Sine Wave Output
-
Product Name:
-
High Current Rectifier for Electroplating Anodizing 0-50V 0-200A
Quick Details
-
Output Power:
-
10000W
-
Input Voltage:
-
220V
-
Output Voltage:
-
0-50V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XINOUHUA
-
Model Number:
-
PA81000
-
Output Frequency:
-
50HZ/60HZ
-
Output Current:
-
0-200A
-
working temperature:
-
0-45
-
Size:
-
370*480*150
-
Protection:
-
Overvoltage
-
operating humidity:
-
10-90
-
efficiency:
-
90%
-
Warranty:
-
1 Year
-
Output waveform:
-
Pure Sine Wave Output
-
Product Name:
-
High Current Rectifier for Electroplating Anodizing 0-50V 0-200A
High Current Rectifier for Electroplating Anodizing PA81000 0-50V 0-200A
High Current Rectifier for Electroplating Anodizing PA81000 0-50V 0-200A
|
PD81000 ADCSeries (Single Phase) AC Power Source |
||||
|
PHASE |
SINGLE PHASE |
THREE PHASE |
||
|
Capacity |
0.5KVA ~ 10KVA |
15KVAK ~ 200KVA |
||
|
INPUT Voltage |
1 φ 2W 220V ± 10% |
3 φ 4W 380V ± 10% |
||
|
INPUT Frequency |
50Hz ~ 60Hz 5% |
|||
|
Working |
SCR+ liner |
thyristor SCR |
SCR+ liner |
thyristor SCR |
|
power effect |
≤ 0. 1% +5mV |
≤ 0. 5% +20mV |
≤ 0. 1% +5mV |
≤ 0. 5% +20mV |
|
load stability rate |
≤ 0.3 % +5mV |
≤ 0.5 % +20mV |
≤ 0.3 % +5mV |
≤ 0.5 % +20mV |
|
current stability |
≤ 0. 5% +5mA |
≤ 1 % +20mA |
≤ 0. 5% +5mA |
≤ 1 % +20mA |
|
stable ripple |
≤ 0. 3% +10mV rms |
≤ 1 % +20mV rms |
≤ 0. 2% +10mV rms |
≤ 0.5 % +20mV rms |
|
constant current ripple |
≤ 0. 5% +10mV rms |
≤ 1 % +20mV rms |
≤ 0. 3% +10mV rms |
≤ 0.5 % +20mV rms |
|
reaction time |
≤ 100uS |
≤1 0mS |
≤ 100uS |
≤1 0mS |
|
voltage setting |
10 turn precision potentiometer |
|||
|
current setting |
10 turn precision potentiometer |
|||
|
voltage display |
4-bit LED digit table precise:≤ 0.5 % +2byte |
|||
|
current display |
4-bit LED digit table precise:≤ 1 % + 3byte |
|||
|
voltage temperature coeffcient |
50~100PPm per degree celsius | |||
|
current temperature coeffcient |
300PPm per degree celsius |
|||
|
Protection |
Over Voltage Over Current Over Temp OverLoad Short Circuit |
|||
|
work environment |
Ambient Temperature:0 ~ 45 ℃ Humidty:10 ~ 90% |
|||
