NEWTOP Outboard Motors and Gearbox Electric Motor Marine For Boat Custom Engine Dimensions Service

NEWTOP Outboard Motors and Gearbox Electric Motor Marine For Boat Custom Engine Dimensions Service

FOB Reference Price: Get Latest Price

≥2 Pieces

US $480

≥10 Pieces

US $460

≥50 Pieces

US $430

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Dimensions (L x W x H) (mm):: /

Brand Name:: NEWTOP

Place of Origin:: ZHE

Product Overview

2-Stroke 5HP Gasoline Outboard Motor

Tried in 3-person boats, this T6 short shaft outboard is powerful in a reliable two-stroke design for optimum performance in all fishing conditions. If you want to go fishing or take a small boat out to sea, T6 outboard is your first choice.

FEATURES AT A GLANCE

Applicable Ship Type:

The 2-stroke 5 horsepower outboard motor is suitable for small vessels of different materials, such as inflatable boats, wooden boats, FRP boats, plastic and so son, ranging from 2.7m to 5.0m.

Fuel Application:

Two-stroke machines use mixed fuel. Gasoline and engine oil should be mixed proportionally.

Gasoline:oil = running-in period 25:1, 50:1 after running-in period.

Other Notes:

This machine has forward, neutral, reverse gear, water cooled system.

Product Model	T5	T6	T7
Engine Type	2-STROKE	2-STROKE	2-STROKE
Idle Speed(r/min)(Neutral position)	1500	1500	1500
Displacement(cc)	102	102	102
Bore x Stroke(mm)	55 x 43	55 x 43	55x43
Max Power Output(kw(ps)/r/min)	3.7(5) @5000	3.7(5) @5000	3.7(5) @5000
Gear Ratio	2.08(27/13)	2.08(27/13)	2.08(27/13)
Transom Height(mm)	S:435 L: 562	S:435 L: 562	S:435 L: 562
Fuel Tank(L)	2.5	2.5	2.5
Propeller Size(in)	3-7 1/2''*8''	3-7 1/2''*8''	3-7 1/2''*8''
Net Weight(kg)	20.5	20.5	20.5
Packing Size(cm)	S: 111 x 60 x 41 L: 123.5 x 65.5 x 43.5	S: 111 x 60 x 41 L: 123.5 x 65.5 x 43.5	S: 111 x 60 x 41 L: 123.5 x 65.5 x 43.5
