Rapeseed peanut soybean steel flat bottom silo for oil mill

Rapeseed peanut soybean steel flat bottom silo for oil mill

FOB Reference Price: Get Latest Price

≥1 Sets

US $12500

≥5 Sets

US $12000

≥10 Sets

US $11500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Dimension(L*W*H):: 19.2m*19.2m*26.93m

Weight:: 68236 KG

Silo Materials:: galvanized corrugated sheets and cement legs

Application:: grain storage steel silo

Handling equipments:: Elevator and conveyor and cleaning system

Galvanized Coating:: 275-600g/m2

Capacity:: 1000---10000 Tons

Monitoring System:: Temperature Level monitoring

Auxiliary system:: Electric Control

Certification:: ISO9001 CE

voltage:: 380/440V or customized

Warranty period:: 1 year

Quick Details

Core Components:: Hot-dip Galvanized Plate

Place of Origin:: Shandong, China

Brand Name:: TSE

Dimension(L*W*H):: 19.2m*19.2m*26.93m

Weight:: 68236 KG

Silo Materials:: galvanized corrugated sheets and cement legs

Application:: grain storage steel silo

Handling equipments:: Elevator and conveyor and cleaning system

Galvanized Coating:: 275-600g/m2

Capacity:: 1000---10000 Tons

Monitoring System:: Temperature Level monitoring

Auxiliary system:: Electric Control

Certification:: ISO9001 CE

voltage:: 380/440V or customized

Warranty period:: 1 year

Products Description

Rapeseed peanut soybean steel flat bottom silo for oil mill

High Standard Large Scale Flat Bottom Grain Silos for Cereal (also called wheat flat bottom bins, flat bins) are commonly selected steel silos or steel bins to storage bulk grains and other materials. Large volume storage is its typical feature, the storage volume of this type grain storage silo ranges from 39 m³ to 29726 m³. These grain bins are erected on flat or conical concrete foundations for long-term storage of large quantities of grain, seeds, pellets and granular products, etc. All our flat silos or flat bins are designed, manufactured and installed in accordance with D-4097 or ASTM D-3299 standards.
The grain flat bottom bins are made of high quality 275g/m2, 300g/m2, 350g/m2 hot-dip galvanized steel plates which are rolled into corrugation and made into standard connecting holes. The vertical friction is support by the steel silo stiffeners which are evenly vertically applied in the silos. The connecting screw bolts are served with round galvanized steel washers, the connecting holes are served with age-resistant and water-proof daub belts that are for aviation special purpose.These plates and stiffeners are connected by high-strength screw bolts to keep the flat silo strong and durable. The flat bottom silos are equipped with flat repairing doors, outside ladder and ladder guard rings.

Main Components of Silos

Product -- Let you use it with peace of mind and take the quality home

Sweeper at the bottom of silo

Sweeper (also called clear dragon) is designed and installed to pick up the remains of stored products and provide good flow through gravity (like wheat, maize, barley, grains and granules, etc.) in the bottom of the flat silos.

It automatically starts up once the gravity flow has completely finished. It will clean up the remained material at a rotation of 360º inside the storage silo.

Specification

Model	Capacity(T/CBM)	Eave Height(M)	Total Height(M)
TCK10014	1318	15.735	18.07
TCK11012	1362	13.5	16.04
TCK13715	2661	16.86	20.06
TCK15516	3660	17.975	21.59
TCK19219	6647	21.335	25.81
TCK25621	12782	23.575	30.96
TCK27520	15009	22.455	30.36

Applications and Advantage for Grain silos

25º Sealed Roof for grain storage silo

The special trapezoidal geometry of roof gives high strength and stiffness. The professional sealed technology enables tight connection of roof with the sidewall and keeps stored products from moisture.

Grain storage silo Cylindrical Body

Shelley Brand hopper bottom silos are made with body sheets and stiffeners, manufactured with structural galvanized steel S350GD of high elastic tolerance and the coating equivalent to 600 g/m2 of zinc.

Concrete Silo Base

The half-cone base or flat base will be constructed when the silo diameter is more than 12m. Half-cone base can’t
completely unload the stuff, it needs to unload stuff with a spiral sweeper. Cement base has a mediate price and a long
construction period.

Flat bottom silo

A flat bottom silo includes the silo roof, manhole, roof guardrail, ventilation window, ladder, silo body, column, and door. It will provide you with a safer, more stable, and more practical experience during use.
