Quick Details
-
Dimension (L*W*H):
-
482*478*132mm
-
Weight:
-
45KG
-
Model No.:
-
RPT 3U
-
Rated Battery Voltage:
-
51.2V
-
Rated Grid Output Current:
-
100A
-
Built-in Battery:
-
LiFePO4
-
Applications:
-
Outdoor and home
-
Certificates:
-
UN38.3,MSDS,UL1973(Cell),IEC62619(Cell)
-
Communicate:
-
RS232-PC,RS485(B)-PC RS485(A)-Inve er,Canbus-Inve er
-
Charging voltage:
-
58.4V±0.5V(16series connection)
Quick Details
-
Model Number:
-
RPT 3U
-
Brand Name:
-
NIUESS, NIUESS
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
482*478*132mm
-
Weight:
-
45KG
-
Model No.:
-
RPT 3U
-
Rated Battery Voltage:
-
51.2V
-
Rated Grid Output Current:
-
100A
-
Built-in Battery:
-
LiFePO4
-
Applications:
-
Outdoor and home
-
Certificates:
-
UN38.3,MSDS,UL1973(Cell),IEC62619(Cell)
-
Communicate:
-
RS232-PC,RS485(B)-PC RS485(A)-Inve er,Canbus-Inve er
-
Charging voltage:
-
58.4V±0.5V(16series connection)
|
Model
|
NE-700/700PRO
|
NE-700PRO
|
NE-1000
NE-1000EX
|
NE-800EX
|
NE-1200
|
|
|
NE-2400
|
RESS-5000B
|
||||||||
|
Output Power
|
700W
|
|
1000W
|
|
1200W
|
|
|
2400W
|
5000W
|
||||||||
|
Capacity
|
512Wh
|
720WH
|
768Wh
|
768Wh
|
922Wh
|
1228Wh
|
1536Wh
|
2304Wh
|
5000Wh
|
||||||||
|
Battery Type
|
LiFePO4
|
NCM
|
LiFePO4
|
LiFePO
|
LiFePO
|
|
|
|
|
||||||||
|
Input
|
AC,Solar,Car Charger
|
|
|
|
|
|
|
|
AC,Solar
|
||||||||
|
Output
|
AC , Cigar lighter,
USB-A , Type-C , DC 5521
|
|
|
|
|
|
|
|
AC
Car charging
|
||||||||
|
Dimension (L*W*H)
|
294*185*236mm
|
|
285*250*259mm
|
|
403*223*298mm
|
|
|
455*295*346mm
|
485*332*630mm
|
||||||||
|
Weight
|
≤7.5KG
|
≤7.7KG
|
8KG
|
|
18KG
|
|
|
28KG
|
70KG
|
||||||||
|
Protection
|
The Built-In BMS Has Multi-Safeguards
|
|
|
|
|
|
|
|
|
||||||||
|
Certification
|
CE/FCC/PSE/RoHS/UKCA/UL/MSDS/UN38.3
|
|
|
|
|
|
|
|
|
||||||||
Product Paramenters
|
Model
|
RPT 3U
|
|
|
||
|
Output Power Range
|
5.12KW
|
|
|
||
|
Energy Storage Capacity(KWh)
|
5.12KWh
|
|
|
||
|
Rated Grid Output Current
|
100A
|
|
|
||
|
Rated AC Voltage
|
51.2V
|
|
|
||
|
Weight
|
45KG
|
|
|
||
|
Size
|
482mm*478mm*132.5mm
|
|
|
||
|
Charging voltage
|
58.4V±0.5V(16series connection)
|
|
|
||
|
Charge Temperature
|
0℃~60℃
|
|
|
||
|
Discharge Temperature
|
-20℃~60℃
|
|
|
||
|
Communicate
|
RS232-PC,RS485(B)-PC RS485(A)-Inve er,Canbus-Inve er
|
|
|
||
|
Battery Type
|
LiFePO4
|
|
|
||
|
Certificates
|
UN38.3,MSDS,UL1973(Cell),IEC62619(Cell)
|
|
|
||
|
Cycle Times
|
6000+ Cycles,10 Years DesignLife Time
|
|
|
||
