Quick Details
-
Power:
-
0.75KW-45KW
-
Dimension(L*W*H):
-
customized
-
Weight:
-
KG
-
Product Name:
-
beer fermentation tank
-
Material:
-
Stainless Steel 304 316L
-
Function:
-
Beer Brewing Equipment
-
Capacity:
-
100-20000L
-
Type:
-
fermenting storage
-
Application:
-
Brewery beer
-
Package:
-
plywoodcases
-
certificate:
-
CE ISO
-
keywords:
-
brewery fermentation equipment
-
Origin:
-
China wenzhou Lenotank
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LENO
-
Voltage:
-
110V-480V
-
Power:
-
0.75KW-45KW
-
Dimension(L*W*H):
-
customized
-
Weight:
-
KG
-
Product Name:
-
beer fermentation tank
-
Material:
-
Stainless Steel 304 316L
-
Function:
-
Beer Brewing Equipment
-
Capacity:
-
100-20000L
-
Type:
-
fermenting storage
-
Application:
-
Brewery beer
-
Package:
-
plywoodcases
-
certificate:
-
CE ISO
-
keywords:
-
brewery fermentation equipment
-
Origin:
-
China wenzhou Lenotank
Products Description
|
Capacity
|
50L to 30000L (1BBL to 100BBL)
|
|
|
|
Jacket
|
Dimple type jacket for Glycol cooling ,with50-80mm PUF insulation layer
|
|
|
|
Processing
|
Fermenting
|
|
|
|
Manhole
|
Shell Side manhole ( top manhole is optional)
|
|
|
|
Thickness
|
3mm
|
|
|
|
Volume design
|
Properly according to the capacity requests
|
|
|
|
Certification
|
ISO9001 / CEI TUV
|
|
|
|
Interior shell
|
Polished
|
|
|
|
Exterior shell
|
2B Plate
|
|
|
|
Material
|
Stainless Steel AlSI 304 or AISI 316
|
|
|
|
Design pressure of the tank
|
1.5bar
|
|
|
|
Design pressure of the jacket
|
3.0bar
|
|
|
|
Parts details
|
60 degree cone bottom
|
|
|
|
|
with an of 25% head space
|
|
|
|
|
25% head space
|
|
|
|
|
Rotating racking port
|
|
|
|
|
Side manway hole, shadowless
|
|
|
|
|
Polyurethane insulation
|
|
|
|
|
CO2 blowoff arm
|
|
|
|
|
Sample Valve
|
|
|
|
|
temperature gauge sensor
|
|
|
|
|
pressure relief valve
|
|
|
We Can Make the Brewing Equipment for Beer, Wine, Sparkling Wine, Whiskey, Gin, Brandy, Rum Etc. The Equipment Capacity From 300l to 30000l. Beer Equipment: Including the Brewhouse, Fermenter, Brita Tank, Cip Trolley Etc.; Wine Equipment: Including the Red Wine/White Wine/Sparkling Wine Tank, Floating Lid Wine Tank and Whole Wine
Used as storage and fermentation tank in wine, dairy industries
Applicable in the field of food, dairy, juice, pharmaceutical chemical and biological fields
All pipes are all ISO or DIN sanitary pipe, internal and external adopt food grade mirror polish
PLC control system, which could achieve automatic, semi-automatic control, to ensure the accurately and effectively of parameters
and experimental results.
The bright beer tank is a tank of store beer, so people also called it a storage tank. They are most applying in the beer
industry, Why they call it a “bright beer tank”?someone also calls it brite beer tank. In fact, after beer fermented and mature,
then need to filter and wipe off the mixed and yeast from the fermentation liquid, make beer clarify and shine. At last, the
fermentation liquid finished filtering is bright beer. This is also the last step of the brewing process, then beer bottling.
Applicable in the field of food, dairy, juice, pharmaceutical chemical and biological fields
All pipes are all ISO or DIN sanitary pipe, internal and external adopt food grade mirror polish
PLC control system, which could achieve automatic, semi-automatic control, to ensure the accurately and effectively of parameters
and experimental results.
The bright beer tank is a tank of store beer, so people also called it a storage tank. They are most applying in the beer
industry, Why they call it a “bright beer tank”?someone also calls it brite beer tank. In fact, after beer fermented and mature,
then need to filter and wipe off the mixed and yeast from the fermentation liquid, make beer clarify and shine. At last, the
fermentation liquid finished filtering is bright beer. This is also the last step of the brewing process, then beer bottling.
Product parameters
|
Technical Parameters
|
|
|
|
|
||||
|
Model
|
Capacity(L)
|
Diameter(mm)
|
Height(mm)
|
conical degree
|
||||
|
7BBL
|
1113L
|
1000
|
1250
|
|
||||
|
10BBL
|
1590L
|
1150
|
1250
|
|
||||
|
15BBL
|
2385L
|
1250
|
1680
|
|
||||
|
20BBL
|
3180L
|
1400
|
1700
|
|
||||
|
30BBL
|
4770L
|
1650
|
1850
|
|
||||
|
40BBL
|
6360L
|
1750
|
2050
|
|
||||
|
50BBL
|
7950L
|
1750
|
2750
|
|
||||
|
60BBL
|
9540l
|
1850
|
2800
|
|
||||
|
80BBL
|
12720L
|
2100
|
2900
|
|
||||
|
100BBL
|
15900L
|
2200
|
3350
|
|
||||
|
We Can Customize The Equipment According To Your Requirements.
|
|
|
|
|
||||
