Quick Details
-
Spindle Taper:
-
MT4 or R8
-
Range of Spindle Speed(r.p.m):
-
95 - 1420 r.p.m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Luzhong Machine
-
Model Number:
-
ZAY7045G
-
Voltage:
-
220V 380V
-
Weight (KG):
-
130
-
Warranty of core components:
-
13 months
-
Name:
-
ZAY7045G Drilling Milling Machines,Drilling and Milling Machine
-
Max. Drilling capacity (mm):
-
45mm
-
face milling capaciy:
-
80mm
-
end milling capacity:
-
32mm
-
spindle nose to table:
-
440mm
-
spindle axis to column:
-
197.5/272.5mm
-
spindle travel:
-
85/130mm
-
spindle taper:
-
MT4 OR R8
-
Table size:
-
800x240mm
-
Power (kW):
-
0.37
Quick Details
-
Table Travel (X) (mm):
-
500
-
Table Travel (Y) (mm):
-
175
-
Table Travel (Z) (mm):
-
130
-
Spindle Taper:
-
MT4 or R8
-
Range of Spindle Speed(r.p.m):
-
95 - 1420 r.p.m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Luzhong Machine
-
Model Number:
-
ZAY7045G
-
Voltage:
-
220V 380V
-
Weight (KG):
-
130
-
Warranty of core components:
-
13 months
-
Name:
-
ZAY7045G Drilling Milling Machines,Drilling and Milling Machine
-
Max. Drilling capacity (mm):
-
45mm
-
face milling capaciy:
-
80mm
-
end milling capacity:
-
32mm
-
spindle nose to table:
-
440mm
-
spindle axis to column:
-
197.5/272.5mm
-
spindle travel:
-
85/130mm
-
spindle taper:
-
MT4 OR R8
-
Table size:
-
800x240mm
-
Power (kW):
-
0.37
Product Description
The main performance characteristics：
1. Gear-driven type and round column
1. Gear-driven type and round column
2.Milling, drilling, boring, reaming
3. Headstock swivels 360 horizontally
4. Micro feed precision
4. Micro feed precision
5. Adjustable gibs on table precision.
6. Strong rigidity, powerful cutting and precisely positioning.
|
Standard accessories:
|
Optional accessories:
|
|
Allen wrench
Drift Spanner Drill chuck rod Screw-driver Draw bar and gasket |
Stand Oil basin Power feed attachment Machine vice Drill chuck Milling cutter holder Reducing sleeve Mill chuck Boring rod Tapping electrical system Coolant system |
|
ITEM
|
ZAY7045G
|
|
Drilling capacity
|
45mm
|
|
Face milling capacity
|
80mm
|
|
End milling capacity
|
32mm
|
|
Distance from spindle nose to table
|
440mm
|
|
Min.distance from spindle
axis to column
|
272.5mm
|
|
Spindle travel
|
130mm
|
|
Spindle taper
|
M.T.4 or R8
|
|
Step of spindle speed
|
6
|
|
Range of spindle speed 50Hz
|
80-1250 r.p.m
|
|
60Hz
|
95-1500 r.p.m
|
|
Swivel angle of headstock
(horizontally/perpendicularly)
|
360°/±90°
|
|
Table size
|
800×240mm
|
|
Forward and backward travel of table
|
175mm
|
|
Left and right travel of table
|
500mm
|
|
Motor power
|
1.5KW(2HP)
|
|
Net weight/gross weight
|
320kg/370kg
|
|
Packing size
|
770×880×1160mm
|
