Quick Details
-
Color:
-
Customized
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
UD-49HB
-
Brightness:
-
2500nits, 2500nits, 1000nits~3000nits
-
Display Ratio:
-
16:9, 16:9
-
Response Time:
-
6ms, 6ms
-
Contrast Ratio:
-
16:9, 16:9
-
Lifespan (hours):
-
50,000hours, 50,000hours
-
Installation Type:
-
Floor stand/Wall Mounted, Floor stand/Wall Mounted
-
View Angle（H/V）:
-
178/178, 178/178
-
Installation:
-
Wall Mountable
-
Warranty:
-
1-3 years
-
Operating system:
-
Android/Windows 7/8/10
-
OSD language:
-
Multi-language Support
-
Touch screen:
-
Capacitive Touch
-
Work mode:
-
24/7/365
-
Support Format:
-
MP4/AVI/RMVB/MKV/GIF/JPG/PNG
-
Certificate:
-
CE FCC ROHS ISO9001
-
Resolution:
-
1920x1080 / 3820x2160
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LCD
-
Brand Name:
-
USENDA
-
Color:
-
Customized
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
UD-49HB
-
Brightness:
-
2500nits, 2500nits, 1000nits~3000nits
-
Display Ratio:
-
16:9, 16:9
-
Response Time:
-
6ms, 6ms
-
Contrast Ratio:
-
16:9, 16:9
-
Lifespan (hours):
-
50,000hours, 50,000hours
-
Installation Type:
-
Floor stand/Wall Mounted, Floor stand/Wall Mounted
-
View Angle（H/V）:
-
178/178, 178/178
-
Installation:
-
Wall Mountable
-
Warranty:
-
1-3 years
-
Operating system:
-
Android/Windows 7/8/10
-
OSD language:
-
Multi-language Support
-
Touch screen:
-
Capacitive Touch
-
Work mode:
-
24/7/365
-
Support Format:
-
MP4/AVI/RMVB/MKV/GIF/JPG/PNG
-
Certificate:
-
CE FCC ROHS ISO9001
-
Resolution:
-
1920x1080 / 3820x2160
Specification
|
Size
|
32”43”49”55”65”75”86”98”
|
|
|
Panel
|
|
|
|
Panel type
|
By L G TFT LCD
|
|
|
Physical Resolution
|
1920x1080/3840x2160
|
|
|
Color depth
|
10bit(D), 1.07Billon colors
|
|
|
Viewing Angle
|
178/178
|
|
|
Luminance(nits)
|
2500cd/m2
|
|
|
Contrast
|
4500:1
|
|
|
Backlit type
|
LED
|
|
|
Response
|
6ms
|
|
|
Life(hrs)
|
more than 60000
|
|
|
Consumption
|
|
|
|
Power Supply
|
AC100~240V 50/60Hz
|
|
|
Standby/Max.Consumption
|
≤1300W
|
|
|
Speaker
|
2x10W
|
|
|
Color System Support
|
PAL/NTSC/SECAM
|
|
|
OSD Language
|
English/Multiple Language
|
|
|
English/Multiple Language
|
Support 1080P,1080I,720P,480P &multiple resolutions
|
|
|
Video format support
|
MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
|
|
|
Image format support
|
JPEG/BMP/TIFF/PNG/GIF
|
|
|
Audio format support
|
Wave/MP3/WMA/AAC
|
|
|
Splicing Display
|
Support
|
|
|
Working Temperature
|
-40℃-50℃
|
|
|
Storage Temperature
|
0℃-50℃
|
|
|
Working Humidity
|
-40%-55%
|
|
|
Storage Humidity
|
5%-95%
|
|
|
Cooling
|
Fan cooling
|
|
|
Appearance &packing
|
|
|
|
Application Condition
|
Pure outdoor all weatherproof
|
|
|
Material
|
Cold-roll steel SPCC
|
|
|
Frame Color
|
Black/White/Silver/Customization
|
|
|
Mount/Installation type
|
Standing,iPhone seamless design
|
|
|
Packing way
|
Safe packing with bubble foam, in wooden case
|
|
|
|
|
|
|
Quality Standard
|
ISO9001,CE,RoHS,FCC,CCC
|
|
Product Description
Key features:
1, Original high brightness LCD panel ,1500nits or up brightness,1920x1080 / UHD 4K 3840x2160 resolution,3000-4000:1
contrast, LED backlight, Sunlight viewable
contrast, LED backlight, Sunlight viewable
2, Special designed LED backlight modular + constant current source drive components
3, Special designed fan cooling system with high-quality fans
4, IP65/IP67 grade all weatherproof dustproof enclosure, +6mm vandal-proof protective glass, +1.5mm SPCC
5, Fan cooling system, and A/C cooling &heating optional
6, Non-network version,
support HDMI VGA USB input, Android OS 5.1+, Windows OS 7/8/10, RS232 board optional
support HDMI VGA USB input, Android OS 5.1+, Windows OS 7/8/10, RS232 board optional
7, Integrated with light sensor, auto
temperature sensor, warning modules, more modules optional
temperature sensor, warning modules, more modules optional
8, Adapt import Akesu paint powder from Germany, 5-7 years no fade,
acid and alkali, professional anti-corrosion more than 5 years
acid and alkali, professional anti-corrosion more than 5 years
9, Auto shut-off function: Auto Shut off upon internal temperature reaches 65℃
10, Integrated with Lightning protection, leakage protection switch, timer
11, Adapt Taiwan Meanwell power, A/C100-240V, 50/60Hz
12, Easy maintenance enclosure plus built-in anti-theft locks
13, Working temperature: -40℃ - 50℃
14, Different designed enclosures can be customized exactly according to client requirements
15, Size 19"22"24"27"32"37"42"43"47"49"50"55"58"60"65"70"72"82"84"85"98" available
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
