1)For B1 class fireproof aluminum composite panel, it contains: 70% flame retardant, the main ingredients are aluminum oxide and magnesium oxide (MgO); When B1 grade panels are put on fire, it can be catched on fire after 5 minutes, and when the fire leave the panels, the fire on the panels will extinguish after 10 seconds.
2)For A2 class fireproof aluminum composite panel, it Contains 93% of the flame retardant,the main ingredients are aluminium hydroxide (Al(OH)3) and magnesium hydroxide (Mg(OH)2); it can be catched on fire after 20 minutes, and the fire will extinguish at once when the fire leave the panels.
ASTM E 84 b1 a2 fireproof durabond alcobond dibond acp 3mm 4x8 cutting machine aluminum plastic composite panels wall cladding
FOB Reference Price:
Get Latest Price
≥900 Square meters
US $6.8
≥2200 Square meters
US $6.6
≥4500 Square meters
US $6.4
≥9000 Square meters
US $2.9
Free Inquiry
Customized Request
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Surface Treatment:
-
Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Megabond
-
Model Number:
-
PE
-
Packing:
-
Pallet,in bulk
-
Output:
-
20,000sqm/day
-
Panel Thickness:
-
3mm
-
Aluminum Thickness:
-
0.18mm
-
Coating:
-
Polyester
-
Transportation:
-
20GP container
-
Quantity:
-
4700sqm/20GP
-
Color:
-
Silver, Gold, More Than 60 Colors
-
Delivery Time:
-
10-15 days
Quick Details
-
Warranty:
-
1 Year
-
Size:
-
1220*2440*4mm, 1500*3200*4mm
-
Project Solution Capability:
-
Others
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Surface Treatment:
-
Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Megabond
-
Model Number:
-
PE
-
Packing:
-
Pallet,in bulk
-
Output:
-
20,000sqm/day
-
Panel Thickness:
-
3mm
-
Aluminum Thickness:
-
0.18mm
-
Coating:
-
Polyester
-
Transportation:
-
20GP container
-
Quantity:
-
4700sqm/20GP
-
Color:
-
Silver, Gold, More Than 60 Colors
-
Delivery Time:
-
10-15 days
fire-retardant Aluminum composite panel
fire-retardant Aluminum composite panel composed of two thin panels of aluminum laminated to either side of a mineral-filled thermoplastic core.
There are 2 kinds of fireproof aluminum composite panel, B1 class and A2 class.
Products Description
|
Normal Width
|
1220mm,1250mm,1500mm,1570mm
|
|
Panel Thickness
|
2mm 3mm 4mm 5mm 6mm
|
|
Aluminum Alloy
|
AA1100,AA3003,AA5005(Other Grade On Requirement)
|
|
Aluminum Thickness
|
0.08mm to 0.50mm
|
|
Coating
|
PE/PVDF/NANO/Anti-scratch/Mill
|
|
PE Core
|
Recycle PE Core/Fireproof PE Core/Unbreakable PE Core
|
|
Color
|
Solid/Metallic/Marable/Woode/Brush/Glossy
|
|
Length
|
5800mm in maximum for 20ft container
|
|
Delivery
|
15 to 20 days after receiving deposit and color confirmed
|
|
MOQ
|
600 to 1000 sqm per color
|
|
Brand/OEM
|
MEGABOND®/CROWNBROND®/Customized
|
|
Payment Terms
|
T/T L/C at sight/Western Union
|
|
Packing
|
FCL:In bulk;LCL;In Wooden Package
|
|
The Contrast Of Fire-resist Grade In Different Countries
|
|
|
|
|
|
|
|
|||||||
|
Standard Burning Degree
|
China
|
Germany
|
U.S.A
|
France
|
U.K
|
Japan
|
Russian
|
|||||||
|
|
GB/T8627
|
DIN 4102
|
ASTM E84
|
BS 476
|
NFF 16-101
|
JIS K6911
|
30244-94
|
|||||||
|
Few
|
A
|
A1,A2
|
NC
|
0
|
MO
|
1
|
T1
|
|||||||
|
Minor
|
B1
|
B1
|
A
|
1
|
M1,M2
|
2
|
T2
|
|||||||
|
Normal
|
B2
|
B2
|
B,C
|
2.3
|
M3
|
3
|
T3
|
|||||||
|
Serious
|
B3
|
B3
|
|
4
|
M4,M5
|
|
|
|||||||
|
Buring Test Report
|
|
|
|
|
||||
|
No
|
Test item
|
Test method
|
Technical index
|
Result
|
||||
|
1
|
Minimum remaining length of combustion,mm
|
GB/T8625-88
|
>0
|
486
|
||||
|
2
|
Average remaining length of combustion,mm
|
GB/T8625-88
|
≥150
|
163
|
||||
|
3
|
Smoke temperature ℃
|
GB/T8625-88
|
≤200
|
78
|
||||
|
4
|
Height of fire,mm
|
GB/T8625-88
|
≤150
|
10
|
||||
|
5
|
Grade of smoke density
|
GB/T8627-88
|
<75
|
9
|
||||
Features
Fireproof Aluminium Composite Panel
MEGABOND fireproof aluminium composite panel is a new type of composite material cored with non-combustible mineral. It has excellent fire resistance as compared with traditional aluminum composite panel. Meanwhile, MEGABOND fireproof ACP conforms to German standard DIN4102 and ASTM E84-05 grade B-1. If you are searching for environmentally friendly building material that offers excellent fire resistance and minimal gas generation when burnt, please try MEGABOND fire resistant aluminum composite panel.
Fireproof aluminum composite panel advantages and characteristics
- Excellent fire resistance, hardly flammable.
- Excellent sound, heat insulation
- Superior impact and peel strength
- Excellent surface flatness and smoothness
- Light weight and easy for maintenance
Projects
MEGABOND fireproof composite panel can be widely used in office buildings, Shopping centers, Industrial buildings, Airports, Hotels, Bus center, Hospitals, Schools, Supermarkets, Residential buildings
|
Technical data of fireproof aluminum composite panel
|
|
|
|
|||
|
Hardly flammable
|
DIN 4102,Part1
|
|
Class B1
|
|||
|
Class B1 Fireproof ACP
|
ASTM E84-05
|
Flame spread index
|
5
|
|||
|
|
|
Smoke developed index
|
0
|
|||
|
Min. rest length of burning
|
GB/T 8625-88
|
≧0mm
|
330mm
|
|||
|
Average rest length of burning
|
GB/T 8625-88
|
≧150mm
|
422mm
|
|||
|
|
DIN 4102,Part1
|
–
|
370mm~480mm
|
|||
|
Smoke temperature
|
GB/T 8625-88
|
≦200℃
|
187℃
|
|||
|
|
DIN 4102,Part1
|
–
|
123℃~160℃
|
|||
|
Flame tip's height
|
GB/T 8625-88
|
﹤150mm
|
15mm
|
|||
|
Smoke density grade
|
GB/T 8627-1999
|
≦75
|
11
|
|||
|
|
DIN 4102,Part1
|
≦400%min
|
10%-16%min
|
|||
