1. Smart multi-function button for switch SPORT/ECO mode,Horn and Turnlights.
2. READY function button and Acceleration bar on the right, three safe steps to start your scooter：①Turn on ignition key; ②Raise up footleg; ③Press the READY button until the green READY symbol appears on the display screen; 4, Speed up your scooter by accelerator.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
maxmov
-
Model Number:
-
Max
-
Certification:
-
EEC/COC
-
Motor power:
-
1600/2000/3000w
-
Battery:
-
60v 20ah lithium
-
Tire:
-
13inch
-
Brake:
-
Oil-hydraulic brake
-
Suspension:
-
Hydraulic Shock Absorber
-
Range:
-
58km
-
max speed:
-
60km/h
-
Net weight:
-
86kgs
-
Color available:
-
Grey/Green/Blue/Red/customize
Quick Details
-
Foldable:
-
Yes
-
Range Per Charge:
-
30-40km
-
Max Speed:
-
30-50Km/h
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
maxmov
-
Model Number:
-
Max
-
Certification:
-
EEC/COC
-
Motor power:
-
1600/2000/3000w
-
Battery:
-
60v 20ah lithium
-
Tire:
-
13inch
-
Brake:
-
Oil-hydraulic brake
-
Suspension:
-
Hydraulic Shock Absorber
-
Range:
-
58km
-
max speed:
-
60km/h
-
Net weight:
-
86kgs
-
Color available:
-
Grey/Green/Blue/Red/customize
|
Product Specification
|
|
|
|
|
||||
|
Model
|
MAX EEC 3000W with all terrian tires
|
|
MAX EEC 2000W with on road tire
|
|
||||
|
Motor Power
|
3000W Brushless Motor
|
|
2000W Hub Motor
|
|
||||
|
Battery
|
60V 20AH Lithium battery
|
|
60V 20AH Lithium battery
|
|
||||
|
Drive Model
|
Chain Drive
|
|
Rear Wheel Drive
|
|
||||
|
Tire Size
|
145/70-6 KENDA All Terrian Tire
|
|
130/50-8 WD On Road Tire
|
|
||||
|
Max Speed
|
45km/h
|
|
|
|
||||
|
Controller
|
MOS-15: 40A
|
|
MOS-15: 38A
|
|
||||
|
Rotation Speed
|
628RPM
|
|
702RPM
|
|
||||
|
Torque
|
45Nm
|
|
27Nm
|
|
||||
|
Battery Type
|
60V 20Ah Lithium 18650 (N.W: 8kg)
|
|
|
|
||||
|
Charger
|
67.2V 2A
|
|
|
|
||||
|
Drive Range
|
45km at max speed
|
|
|
|
||||
|
Max Loading
|
120kg
|
|
|
|
||||
|
Wheelbase
|
1050mm
|
|
|
|
||||
|
Ground Clearance
|
120mm
|
|
|
|
||||
|
Frame Material
|
High-tensil Steel Tube
|
|
|
|
||||
|
Front Absorber
|
Motorcycle Hydraulic Up-side Down Damping Shocks
|
|
|
|
||||
|
Brake System
|
Front and Rear Oil-Hydraulic Disc Brake
|
|
|
|
||||
|
Foot Pedal
|
Aluminum Deck
|
|
|
|
||||
|
Rear Absorber
|
Hydraulic Damping Spring Shocks
|
|
Alloy Case Spring Shocks
|
|
||||
|
Headlight
|
Double LED Low-beam
|
|
Single photosensitive LED lights
|
|
||||
|
Taillight
|
LED
|
|
|
|
||||
|
Turnlights
|
YES
|
|
|
|
||||
|
Horn
|
YES
|
|
|
|
||||
|
Mirror
|
YES
|
|
|
|
||||
|
Reflector
|
YES
|
|
|
|
||||
|
Start Mode
|
Ignition Key
|
|
|
|
||||
|
Speedometer
|
Sport-style LCD display
|
|
|
|
||||
|
Net Weight
|
57kg (including the battery)
|
|
|
|
||||
|
Dimension(LxWxH)
|
1430 x 650 x 1410mm
|
|
|
|
||||
|
Package Size(LxWxH)
|
1450 x 335 x 670mm
|
|
|
|
||||
|
Qty 20ft/40ft/40hq
|
84units / 168units / 224units
|
|
|
|
||||
|
Standard Color
|
Black, Customize
|
|
|
|
||||
Chain drive motor & off-road tire
3000w Brushless motor have more power.145/70-6 KENDA off-road Tire suitable for all terrian
Single city style headlights
1. Single city style headlights more brighter2. Front turn lights signal
3. More safer with yellow and red reflector for night.
Mini LED taillight & New motorcycle taillight
The new photosensitive headlamps include Low beam lamps and Daytime running lamp, which have automatic light sensing function. The
Daytime running lamp is turned on in a bright environment, and the Low beam is automatically turned on in a dim environment.
Hydraulic suspension and hydraulic brake system
1. CNC manufacturing process upper and lower clamper for front fork.
2. Front double up-side down hydraulic suspensions.
3. Oil-Hydraulic Brake with 16MM Disc can be used by spot brake to stop the scooter brake quickly and in short distance.
3. Oil-Hydraulic Brake with 16MM Disc can be used by spot brake to stop the scooter brake quickly and in short distance.
Rear double hydraulic spring shocks
The shock could be customize the colors, basic color is black.
Rear double alloy case spring shocks
The shock could be customize the colors, basic color is black.
Saddle
The large-sized seat cushion features a diamond pattern and a red rear reflector for both comfort and safety during ridingThe
detachable seat cushion rod is equipped with a height adjustment rod of 31.8MM and a 150MM adjustment range.
Saddle post & Foldable
The foldable steering reduces the overall height of the vehicle, making it easier for transportation or storage.
Multi-function Operation Bar
Q1: What is MOQ?
20pcs for ecch item.
Q2: Whats is your sample policy?
Sample is available. Customer have to pay for the sample cost and shipping cost. Once place FCL order, the sample cost will be
returned back 100%. 0
Q3. What is your payment terms?
100% payment before production for sample order;50% deposit , 50% against the Bill of Lading copy for LCL order;
30% deposit , 70% against the Bill of Lading copy for FCL order.
Q4. How about the delivery time ?
5-10 days for sample order;7-25 days for LCL order;
15-30 days for FCL order.
Q5. What's your shipment terms ?
All prices quoted are FOB NINGBO or SHANGHAI price. EXW, FOB, CIF, DDU are all acceptable.
Q6. Could you customize the scooter according to different requirements?
Yes, sure. We have metalworking workshop and more than 10 years scooter experience R&D team can perfectly complete your any
modification and design. Have got a lot of success, such as EVOKING, BOSSMAN-S, and KNUMO. Sticker and shipping mark with your
logo can be customized as well.
Q7. Any discount ?
For wholesale order, pls kindly contact us for final price.
20pcs for ecch item.
Q2: Whats is your sample policy?
Sample is available. Customer have to pay for the sample cost and shipping cost. Once place FCL order, the sample cost will be
returned back 100%. 0
Q3. What is your payment terms?
100% payment before production for sample order;50% deposit , 50% against the Bill of Lading copy for LCL order;
30% deposit , 70% against the Bill of Lading copy for FCL order.
Q4. How about the delivery time ?
5-10 days for sample order;7-25 days for LCL order;
15-30 days for FCL order.
Q5. What's your shipment terms ?
All prices quoted are FOB NINGBO or SHANGHAI price. EXW, FOB, CIF, DDU are all acceptable.
Q6. Could you customize the scooter according to different requirements?
Yes, sure. We have metalworking workshop and more than 10 years scooter experience R&D team can perfectly complete your any
modification and design. Have got a lot of success, such as EVOKING, BOSSMAN-S, and KNUMO. Sticker and shipping mark with your
logo can be customized as well.
Q7. Any discount ?
For wholesale order, pls kindly contact us for final price.
