Quick Details
-
Model Number:
-
JX-200
-
Warranty:
-
15 Months
-
Overall Height:
-
2824mm
-
Width:
-
3380mm
-
Min Height:
-
100mm
-
Frequency:
-
50Hz or 60Hz
-
Power:
-
2.2kw;380v/220v
-
Lifting Time:
-
50seconds
-
Net Weight:
-
530kg
Quick Details
-
Lifting Capacity:
-
3500kg
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
WT
-
Model Number:
-
JX-200
-
Warranty:
-
15 Months
-
Overall Height:
-
2824mm
-
Width:
-
3380mm
-
Min Height:
-
100mm
-
Frequency:
-
50Hz or 60Hz
-
Power:
-
2.2kw;380v/220v
-
Lifting Time:
-
50seconds
-
Net Weight:
-
530kg
1.Dual hydraulic cylinders drive, stable lifting and lowering. Adopt two steel cables for equalization, force two carriages to move synchronously.
2.Manual lock release mechanism on both sides
2. Ensure more security in operation by traveling limitation.
3. Aluminum motor prevents overheating caused by long time working.
4. Door opening protection rubber bar effectiovely avoid damages.
5. Optional 3-section arm design is suitable for different length adjustment.
6. Lowering limited switch reminding function effectively prevents injuries and damages.
7. Lowering alarm system ensures safety.
8. Its elegant appearance design of column cover and hose inside installation.
9. Positive results of dynamic test with 115% of rated capacity and static test with 150% of rated capacity.
|
Lift Capacity |
3500kg |
|
Overall Height |
2824mm |
|
Overall Width |
2770mm |
|
Width (Inside of columns) |
3380mm |
|
Height (From limit to ground) |
1850mm |
|
Min. height from the pad to the ground |
100mm |
|
Power |
2.2kw; 380v/220v
|
Q1: Are you a trading company or manufacturer?
- We are the manufacturer with Exporting License.
2. Can you do OEM for us ?
- OEM are welcome for us. Customers’ brand, logo, label can be customized for product and carton package, but based on a certain quantity.
3. Can you help us to do some change about your product?
- Yes, special drawing and design will be evaluated by our technical department, unit cost will be calculated by finance department for your final confirmation. All procedures will be informed and confirmed with you in advance.
