YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor
YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor

YET610B Universal AC/DC 12 / 24V photoelectric 15 Meters Automatic safety Photocell Infrared beam Sensor

FOB Reference Price: Get Latest Price
≥50 Sets
US $4.07
≥200 Sets
US $3.91
≥500 Sets
US $3.81
≥2000 Sets
US $3.68
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Mounting Type:
Nailed to the wall
Description:
Send an alarm through infrared ray, beam sensor
Manufacturing Date Code:
no
Model Number:
YET610B
Place of Origin:
Guangdong, China
Brand Name:
YET
Theory:
Photocell Infrared Sensor
Output:
AC/DC12 / 24V, Switching Transducer
Name:
Universal AC/DC12 / 24V 1 Beam 15 Meters Automatic Photocell
Working current:
40mA
Wave length:
940nm
Input:
r*15ma - t*30ma
Operating temperature:
-20 degrees to 50degrees
Relay output:
1 a max *36 v
range:
can be reduced to 30% in bad weather conditions : for rain ,dust ,etc
Size:
49.2 x 76 x 21.6M
Usage:
Door sensor

Quick Details

Use:
universal automatic door and window
Series:
sensor
Features:
Emitting infrared light
Mounting Type:
Nailed to the wall
Description:
Send an alarm through infrared ray, beam sensor
Manufacturing Date Code:
no
Model Number:
YET610B
Place of Origin:
Guangdong, China
Brand Name:
YET
Theory:
Photocell Infrared Sensor
Output:
AC/DC12 / 24V, Switching Transducer
Name:
Universal AC/DC12 / 24V 1 Beam 15 Meters Automatic Photocell
Working current:
40mA
Wave length:
940nm
Input:
r*15ma - t*30ma
Operating temperature:
-20 degrees to 50degrees
Relay output:
1 a max *36 v
range:
can be reduced to 30% in bad weather conditions : for rain ,dust ,etc
Size:
49.2 x 76 x 21.6M
Usage:
Door sensor

Universal AC/DC12 / 24V 1 Beam 15 Meters Automatic Photocell Infrared Sensor

Quick Details

Usage: Door sensor
Infrared Frequancy : 1.92khz
Power supply : 12 to 24 VDC /AC
Output: Switching Transducer
Working current: 40mA
Wave length: 940nm
Input: r*15ma - t*30ma
Operating temperature: -20 degrees to 50degrees
Relay output: 1 a max *36 v
Dimension: 49.2 x 76 x 21.6mm
range: can be reduced to 30% in bad weather conditions : for rain ,dust ,etc
Name: mini gate opener motor photocell sensor

Packaging & Delivery

Packaging Details: 80sets/ctn ctn size:48*38*25cm
Delivery Detail: 15 days for 5000-10000pcs

Features:

1.Single beam sensor/single beam detector is used for automatic slide door, coil door , garage door windows etc.

2.Consists of a transmitter and a receiver, and the integrated amplifier can produce infrared beam.

Narrow infrared beam (I or II) can avoid interruption by external light.

3.Even installed at low height(20-40cm from the floor), the detecting distance can also be guaranteed(5-15meters).

4.The beam produced by MICROCELL provides a self-detecting function for the sliding doors. Once the self-detecting beam is interrupted, the door will stop closing and reverse rapidly to the utmost width. The door will open until the detecting beam is resumed. When the door completely closes, the detecting beam becomes invalid.
