Quick Details
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
Smart
-
Model Number:
-
IDP SMART-50D
-
Place of Origin:
-
South Korea
-
Printing Method:
-
Edge-to-Edge printing
-
Printer Dimension:
-
170mm (W) x 195mm (H) x 420mm (D)
Quick Details
-
Max Paper Size:
-
CR80
-
Black Print Speed:
-
720 cards/hour in monochrome one side
-
Color Print Speed:
-
144 cards/hour in full color one side (YMCKO)
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
Smart
-
Model Number:
-
IDP SMART-50D
-
Place of Origin:
-
South Korea
-
Printing Method:
-
Edge-to-Edge printing
-
Printer Dimension:
-
170mm (W) x 195mm (H) x 420mm (D)
IDP SMART-50D ID Card Printer Dual-Sided with LED&LCD
(Use SIADC-S-YMCKO 650643 or SIADC-P-YMCKO 650634 color ribbon)
Overview
--This Smart ID card printer delivers reliable performance, high quality and user's convenience.
--It is ideal for small to mid-sized corporations, banks, schools and government facilities.
--Dual or Single-sided direct thermal printing of photos, bar codes, digitized signatures and various encodings.
Features
1. Cost Competitiveness
- Prevent the waste of ribbon panel by perfect auto ribbon search function
- Free bundle design software (Smart Design)
2. Excellent Convenience
- Show real-time process status through 2 lines LCD window
- Front card In/Out system (Front side Hopper & Stacker)
- Convenient semi-cartridge type’s ribbon & cleaning roller
- Easy Contact/Contactless/Mobile IC encoding
3. Clear Printing Quality
- Apply FINE Imaging Technology to make clear and optimized color
- Print high quality mono image with Resin using High Quality Dithering Algorithm
4. Enhanced Printing Speed
- Max 144 cards/hour in full color one side (YMCKO)
- Max 120 cards/hour in full color two side(YMCKOK) (with Rotator)
- Max 720 cards/hour in monochrome one side
5. Various Option
- Magnetic Stripe Encoding : ISO 7811, JIS2, HiCo / LoCo
- IC (Contact) Encoding : ISO 7816 (ID-1)
SIM Type - ISO 7816 (ID-000)
- Two Contactless Encodings (Internal & External) : ISO 14443 (Type A / B), ISO 15693, MIFARE
- Rotator
6. Easy Card Issuing
- Provide exclusive design and encoding tool (Smart Design)
- Easy connection with external database
- Compatible with MS Excel/Word/Power Point and Photoshop program
7. Dual-Sided Printing
- Dual-sided printing with attachable Rotator
- Apply latest Optimal Rotating Technology (Rotate in a second without noise)
Specification
| Smart Dual-sided Card Printer | |
| * Card Types | PVC, Polyester Cards with polished PVC finish |
| * Printing Method | Dye-Sublimation / Resin Thermal Transfers / Edge-to-Edge |
| * Card Format | ISO CR-80 |
| * Card Thickness | 0.38mm (15mil), 1.0mm (40mil) |
| * Resolution | 300 dpi |
| * Memory | 64MB |
| * Printing Speed | Color (Y.M.C.K.O) : max 144 cards/hour |
| Mono (Black) : max 720 cards/hour | |
| Black Overlay (K.O) : max 360 cards/hour | |
| Color (Y.M.C.K.O.K) : max 123 cards/hour | |
| * Ribbon Capacity | Color (Y.M.C.K.O) : 250 cards/roll |
| Black Overlay (K.O) : 600 cards/roll | |
| Mono : 1,200 cards/roll (Black, Gold, Silver) | |
| Color (Y.M.C.K.O.K) : 200 cards/roll | |
| * Hopper & Stacker | Hopper : 90 cards, Stacker : 40 cards |
| * Interface | USB |
| *Display | 2 Line LCD & LED |
| * Power | Free Voltage (110/240V AC), 50 ~ 60 Hz, 45W |
| * Dimension | 170mm (W) x 195mm (H) x 420mm (D) |
| * Operating Environment | Temperature : 10 ~ 35, Humidity : 20 ~ 80% |
| * Weight | 4.5 kg |
| * Agency Listing | MIC, CE, UL, FCC |
| * Printer Driver | Windows 2000 / 2003 / XP/7/8/Vista/Linux |
| Option | |
| * M/S Encoding | ISO 7811 (Track,, Read / Write), JIS, HiCo / LoCo |
| * IC (Contact) Encoding |
ISO 7816 (ID-1)
SIM Type-ISO 7816(ID-000) |
|
* Two RF Encodings
(Internal & External) |
ISO 14443 (Type A / B), ISO 15693, MIFARE |
| * Card Rotator | Default |
