Quick Details
-
Graphic Format Supported:
-
AI, PLT, BMP, Dwg
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Grentsun
-
Dimension(L*W*H):
-
85cm*60cm*45cm
-
Weight (KG):
-
80 KG
-
Core Components:
-
Laser source, Galvanometer
-
marking speed:
-
≤7000mm/s
-
laser power:
-
3w
-
frequency:
-
20KHZ-80KHZ
-
marking area:
-
110mmx110mm
-
cooling system:
-
water cooling
-
Laser wavelength:
-
1064nm
-
Laser source:
-
Raycus Laser Source
Quick Details
-
Engraving Area:
-
110x110mm 175x175mm 300x300mm
-
Laser Type:
-
UV laser
-
Engraving Speed:
-
≤7000mm/s
-
Graphic Format Supported:
-
AI, PLT, BMP, Dwg
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Grentsun
-
Dimension(L*W*H):
-
85cm*60cm*45cm
-
Weight (KG):
-
80 KG
-
Core Components:
-
Laser source, Galvanometer
-
marking speed:
-
≤7000mm/s
-
laser power:
-
3w
-
frequency:
-
20KHZ-80KHZ
-
marking area:
-
110mmx110mm
-
cooling system:
-
water cooling
-
Laser wavelength:
-
1064nm
-
Laser source:
-
Raycus Laser Source
Product Picture
Product Paramenters
|
Name of Series
|
GSL-U series
|
|
|
|
|||
|
Product Name
|
3W 5W UV laser marking machine CCD system on PE ABS PP 3C parts charger plug
|
|
|
|
|||
|
Laser Power
|
3W/5W/10W/15W
|
|
|
|
|||
|
Laser Wavelength
|
355nm
|
|
|
|
|||
|
Laser Beam Quality
|
M2:<1.8
|
|
|
|
|||
|
Repeat Positioning Accuracy
|
0.003mm
|
|
|
|
|||
|
Min.Linear Width
|
0.01mm
|
|
|
|
|||
|
Marking Depth
|
0.01-1mm(varies with material)
|
|
|
|
|||
|
Max.Marking Speed
|
7000mm/s
|
|
|
|
|||
|
Standard Marking Area
|
175*175mm
|
|
|
|
|||
|
Optional Marking Area
|
110*110mm/200*200mm/300*300mm/400*400mm
|
|
|
|
|||
|
Ranted Power
|
<500W
|
|
|
|
|||
|
Rated Voltage
|
220V/50Hz/15A & 110V/50Hz/15A
|
|
|
|
|||
|
Cooling
|
Water Cooling/Air Cooling
|
|
|
|
|||
|
Lifetime of source
|
20,000hrs
|
|
|
|
|||
|
Warranty
|
1 year for complete machine
|
|
|
|
|||
|
Gross Weight
|
70kg
|
|
|
|
|||
|
Dimension of Package
|
850*650*450mm
|
|
|
|
|||
|
Area Needed
|
600*800*1550mm
|
|
|
|
|||
