Quick Details
-
Brand Name:
-
BENXU
-
Model Number:
-
BX-S800a/b/c/e
-
Max. Current:
-
16A
-
Operating Temperature:
-
-45 to 80℃
-
Protection Level:
-
IP65
-
Rated voltage current:
-
AC-12 Uec380V/16A DC-12 Ue110V/10A
-
Allowable operating speed:
-
0.5mm-1m/s
-
Allowable operating frequency:
-
Machinery:max 120 times/min Machinery:min 20 times/min
-
Contact resistance:
-
25M ohms
-
Insulation resistance:
-
100M ohms(AC4000V)
-
Withstand voltage power frequency:
-
Rated withstand voltage 4KV
-
Anti-vibration:
-
10-55Hz 1.5mm double vibration radiation
-
Shock:
-
lasting long:max 4000m/Sec2 Malfunction:300m/Sec2
-
The lifetime:
-
Machinery:more than 1 million times Electric: More than 200,000 times
-
Protection Class:
-
IP65
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
380VAC
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
BENXU
-
Model Number:
-
BX-S800a/b/c/e
-
Max. Current:
-
16A
-
Operating Temperature:
-
-45 to 80℃
-
Protection Level:
-
IP65
-
Rated voltage current:
-
AC-12 Uec380V/16A DC-12 Ue110V/10A
-
Allowable operating speed:
-
0.5mm-1m/s
-
Allowable operating frequency:
-
Machinery:max 120 times/min Machinery:min 20 times/min
-
Contact resistance:
-
25M ohms
-
Insulation resistance:
-
100M ohms(AC4000V)
-
Withstand voltage power frequency:
-
Rated withstand voltage 4KV
-
Anti-vibration:
-
10-55Hz 1.5mm double vibration radiation
-
Shock:
-
lasting long:max 4000m/Sec2 Malfunction:300m/Sec2
-
The lifetime:
-
Machinery:more than 1 million times Electric: More than 200,000 times
-
Protection Class:
-
IP65
Why choose BENXU?
♦ Focus on Sensor Production all the time
♦ T he B est Quality with Reasonable Factory Directly Price
♦ Have Passed CE,RoHS etc Certificates
♦ 18 Months Quality Guarantee S tarting from the Date of Delivery
Do you care about followings after place an order?
♦ Quality problem?
BENXU signs the 18 months warranty of quality with you.
♦ Price problem?
If think price is higher at same top quality by comparison with others,we will refund you.
♦ After sale problem?
Artificial damage:will offer technical support.
Quality problem:will do repair or offer replacement without any cost within 18 months.
♦ Can’t deliver in time or some other problems?
Go ahead with Trade Assurance Online:
Characteristic s:
1,T he contact action is sensitive and reliable,the precision is high,the service life is long,and the appearance is beautiful .
2,Adopt the engineering plastics with excellent insulation properties which have the characteristics of fire resistance,enhancement,high heat resistance and durability.
3,Can be customized according to different requirements.
Application s:
Factory general equipment,mining industry,construction machinery
Locomotive room equipment ,Electric power industry,In the field of ships
Technical Parameters:
|
Rated voltage current |
AC-12 Uec380V/16A DC-12 Ue110V/10A |
|
Allowable operating speed |
0.5mm-1m/s |
|
Allowable operating frequency |
Machinery:max 120 times/min Machinery:min 20 times/min |
|
C ontact resistance |
25M ohms |
|
I nsulation resistance |
100M ohms (AC4000V) |
|
Withstand voltage power frequency |
Rated withstand voltage 4KV |
|
Anti-vibration |
10-55Hz 1.5mm double vibration radiation |
|
Shock |
lasting long:max 4000m/Sec2 Malfunction :300m/Sec2 |
|
The lifetime |
Machinery:more than 1 million times E lectric : More than 200 , 000 times |
|
Ambient temperature |
-45 to 80 ℃ |
|
Protection Class |
IP65 |
|
Performance characteristic |
OT-3.5N FP-1.9N RP-0.8N |
Dimensional Drawing(unit:mm):
BX-S800a:
BX-S800b:
BX-S800c:
BX-S800e:
