Quick Details
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
swmotoren
-
Model Number:
-
SGE315-AM-092
-
Model:
-
SGE315-AM-092
-
Certification:
-
ce
Quick Details
-
Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
-
Electric Current Type:
-
AC
-
Mounting:
-
FREE STANDING
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
swmotoren
-
Model Number:
-
SGE315-AM-092
-
Model:
-
SGE315-AM-092
-
Certification:
-
ce
Product Description
| Specification | |||||||
| Model Type: SGE315-AM-092 | |||||||
| Rated Voltage | Frequency | Rated Current | Input Power | Speed | Air Flow | Sound Pressure Level | |
| (VAC) | (Hz) | (A) | (W) | (RPM) | (m3/h) | (db) | |
| 220 | 50/60 | 1.1 | 165 | 2100 | 2440 | 66 | |
| Details Description | |||||||
| Leakage Current(ma) | 5 Max | ||||||
| Dielectric Resistance | AC 1800V | ||||||
| Insulation Class | B Class | ||||||
| Control Input | 0-10V Vdc/PWM | ||||||
| Output | +10Vdc | ||||||
| Tach Output | 1 Pulse/R | ||||||
| Protected Mode | Over-Temperatuer/Over-Current/Locked Protected | ||||||
| Characteristic Curves | |||||||
|
|
|||||||
| Drawing | |||||||
|
|||||||
