Quick Details
-
Inertial measurement:
-
yes
-
Electron bubble:
-
Support automatic measurement
-
Material:
-
Magnesium alloy AZ91D body
-
Weight:
-
0.79kg
-
GPS:
-
L1 CA/L1P/L1C/L2P/L2C/L5
-
BEIDOU:
-
B1I/B2I/B3I/ B1C/B2a
-
Battery:
-
Built-in non-removable battery
-
Name:
-
Beidou Zhongyi
Quick Details
-
Warranty:
-
1 years
-
Place of Origin:
-
Shanghai, China
-
Channel:
-
1590
-
Inertial measurement:
-
yes
-
Electron bubble:
-
Support automatic measurement
-
Material:
-
Magnesium alloy AZ91D body
-
Weight:
-
0.79kg
-
GPS:
-
L1 CA/L1P/L1C/L2P/L2C/L5
-
BEIDOU:
-
B1I/B2I/B3I/ B1C/B2a
-
Battery:
-
Built-in non-removable battery
-
Name:
-
Beidou Zhongyi
Products Description
Technical parameter
|
|
Channels
|
1598
|
|
|
GPS
|
L1C/A,L2P,L1C,L2C,L5
|
|
|
GLONASS
|
G1C,G1P,G2C,G2P,G3
|
|
|
Galileo
|
E1,E5b,E5a,E5AltBoc,E6c
|
|
|
BDS-2
|
B1, B2, B3
|
|
|
BDS-3
|
B1C,B2a,B2b,B2b-ppp
|
|
|
SBAS
|
L1C/A,L5C
|
|
|
QZSS
|
L1C/A,L2C,L5,L1C,L1s,L5s,L6
|
|
|
IRNSS
|
L5
|
|
GNSS Accuracies
|
Static and Fast Static
|
Horizontal: 2.5 mm + 0.5 ppm
Vertical: 5 mm + 0.5 ppm |
|
|
Long Observations Static
|
Horizontal: 3 mm + 0.1 ppm
Vertical: 3.5 mm + 0.4 ppm |
|
|
Real Time Kinematic
|
Horizontal: 8mm+1ppm
Vertical: 15 mm + 1 ppm |
|
|
DGPS
|
<0.4 m RMS
|
|
|
SBAS
|
1 m 3D RMS
|
|
|
Standalone
|
1.5 m 3D RMS
|
|
|
PPP
|
Horizontal：10cm ；Vertical：20cm
|
|
Hardware
|
Size
|
Ф130*65.5mm
|
|
|
Weight
|
790g
|
|
|
Environment
|
Operating:-30℃—+65℃
Storage: -40℃—+85℃ |
|
|
Humidity
|
100% condensation
|
|
|
Ingress protection
|
IP67
|
|
|
Shock
|
Survive a 2-meter pole drop
|
|
|
Tilt sensor
|
Calibration-free IMU integrated for tilt survey up to 60°tilt with 2.5 cm accuracy
|
|
|
Serial port
|
supports serial communication
|
|
|
USB
|
TYPE-C interface
|
|
|
Data protocols
|
LTE-FDD, LTE-TDD, DC-HSDPA HSPA+、HSDPA、HSUPA、WCDMA、 TD-SCDMA、CDMA、EDGE、GPRS
|
|
|
Antenna
|
Three in one antenna
|
|
|
Data formats |
NMEA-0183： GPGGA、GPGSV、GPGSA、GPRMC、 GPVTG、GPZDA
Sinan binary format: cnb (sinognss custom) RTCM2.x： RTCM1B、RTCM3B、RTCM9B、
RTCM1819B、RTCM59B
RTCM3.0： 1004、1005、1006、1007、1008、1011、 1104、1033
RTCM3.2： MSM4、MSM5
|
|
|
WIFI
|
802.11b/g/n
|
|
|
Power consumption
|
1.4W
|
|
|
Battery Capacity
|
≤30h
|
|
|
Input voltage:
|
6-28 VDC
|
|
|
Shell material
|
magnesium aluminum alloy shell
|
