Quick Details
-
Material:
-
Aluminium alloy front bezel +High strength cold rolled steel back case
-
Contrast Ratio:
-
1000:1
-
Brightness:
-
1000nits, sunlight readable
-
IP Grade:
-
Full IP67 Waterproof
-
Working voltage:
-
12V
-
OEM/ODM:
-
Support
-
Application:
-
Outdoor cabinet, vending machine, self-service ticket controller
-
Certificate:
-
CE, RoHS and FCC
-
Warranty:
-
12months
Quick Details
-
Type:
-
Resistive
-
Brand Name:
-
Sihovision
-
Place of Origin:
-
Guangdong, China
-
Material:
-
Aluminium alloy front bezel +High strength cold rolled steel back case
-
Contrast Ratio:
-
1000:1
-
Brightness:
-
1000nits, sunlight readable
-
IP Grade:
-
Full IP67 Waterproof
-
Working voltage:
-
12V
-
OEM/ODM:
-
Support
-
Application:
-
Outdoor cabinet, vending machine, self-service ticket controller
-
Certificate:
-
CE, RoHS and FCC
-
Warranty:
-
12months
Features
1. Robust and durable all-metal enclosure, sealing design, full IP67 waterproof
2. Industrial LCD panel, high brightness 1000 nits,sunlight readable
3. Adopt high precision industrial 5 wire resistive touch screen.
4. High performance mainboard, 7x24 continuous operation.
Specification
|
Model:SL121W |
|
|
LCD panel |
|
|
Panel size |
12.1" |
|
Resolution |
1024*768 |
|
Aspect ratio |
4:3 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits , sunlight readable |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
5 wire resistive touch |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
<5ms |
|
Luminousness |
85% |
|
Surface Hardness |
3H |
|
Working Life |
>35 million times |
|
Touch options |
( PCAP touch optional) |
|
Singal Ports |
|
|
VGA |
1×HDMI |
|
VGA |
optional |
|
DVI |
optional |
|
AV |
optional |
|
Audio in/out |
optional |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
|
Support OS |
Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V |
|
Working voltage |
12 V |
|
Power consumption |
25 W |
|
Enclosure |
|
|
Material |
aluminium alloy front bezel +High strength cold rolled steel back case |
|
Color |
Black, white, Silver , color can be customized |
|
VESA mounting |
75×75/100×100 mm |
|
IP-grade |
IP67 |
|
Operating Environment |
|
|
Temperature Range |
operating: -10°C to 60°C, storage :-20°C to 70°C |
|
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
|
Packing Details |
|
|
Net weight |
3kg |
|
Gross weight |
5kg |
|
Product Dimension |
32×25×4.78cm |
|
Packing size |
50×41×18cm |
|
Accessories |
Power adapter, HDMI/USB cable |
