Quick Details
-
Span:
-
35m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Vanbon/OEM
-
Weight (KG):
-
1000 kg
-
Product Name:
-
2 ton crane
-
power:
-
AC 220-690V 50Hz
-
Crane feature:
-
european overhead bridge crane
-
ISO9001:2008:
-
passed
-
CE certification:
-
passed
-
working temperature:
-
-33~46 degree
-
speed control:
-
Resistance/Frequency conversion/Regulator
-
Control method:
-
Wireless remot/Cabin/Room control
-
Work Duty:
-
A3-A5
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Max. Lifting Height:
-
20m
-
Rated Lifting Moment:
-
20-500kN
-
Max. Lifting Load:
-
2.5-62.5t
-
Span:
-
35m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Vanbon/OEM
-
Weight (KG):
-
1000 kg
-
Product Name:
-
2 ton crane
-
power:
-
AC 220-690V 50Hz
-
Crane feature:
-
european overhead bridge crane
-
ISO9001:2008:
-
passed
-
CE certification:
-
passed
-
working temperature:
-
-33~46 degree
-
speed control:
-
Resistance/Frequency conversion/Regulator
-
Control method:
-
Wireless remot/Cabin/Room control
-
Work Duty:
-
A3-A5
-
After-sales Service Provided:
-
Video technical support
Product Display
| Lifting capacity(t) | 2 | 5 | 7.5 | 10 | 15 | 20 | 25 | 32 | 50 | |
| Span(m) | 8-35 | |||||||||
| Max lifting height(m) | 20 | 14 | 18 | 14 | ||||||
| Main lifting speed(m/min) | A5 | 12.6 | 12.6 | 8.5 | 8.5 | 7.9 | 7.2 | 8.5 | 7.5 | 5.9 |
| A6 | 15.6 | 15.6 | 13.3 | 15.6 | 13.3 | 13 | 12.5 | 9.5 | 7.8 | |
| Trolley travelling speed(m/min) | 37.2 | 37.2 | 43.8 | 37.2 | 43.8 | 44.6 | 44.6 | 42.4 | 38.5 | |
| Main lifting motor(m/min) | a5 | 13 | 13 | 17 | 13 | 17 | 26 | 26 | 42 | 55 |
| q6 | 15 | 15 | 22 | 15 | 22 | 37 | 45 | 55 | 75 | |
| Trolley motor(kW) | 2.5 | 2.5 | 2.5 | 1.8 | 2.2 | 3.7 | 3.7 | 5.5 | 7.5 | |
| Work duty | A5-A6 | |||||||||
| Power supply |
AC 220-690V,50Hz |
|||||||||
