Quick Details
-
Brand Name:
-
SOCMA
-
Fork Length:
-
1200mm
-
Fork Width:
-
180mm
-
Overall Dimensions:
-
6055*2250*3100mm
-
Model:
-
HNF-120
-
Type:
-
Manual Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Product Name:
-
Forklift
-
Power type:
-
Diesel Diesel Forklift
-
Engine:
-
Optional
-
Loading Capacity:
-
12 ton
-
Product Type:
-
Heavy duty forklift
-
Color:
-
Customer Demanded
-
Feature:
-
Low Consumption
Quick Details
-
Min. Lifting Height:
-
3100mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SOCMA
-
Fork Length:
-
1200mm
-
Fork Width:
-
180mm
-
Overall Dimensions:
-
6055*2250*3100mm
-
Model:
-
HNF-120
-
Type:
-
Manual Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Product Name:
-
Forklift
-
Power type:
-
Diesel Diesel Forklift
-
Engine:
-
Optional
-
Loading Capacity:
-
12 ton
-
Product Type:
-
Heavy duty forklift
-
Color:
-
Customer Demanded
-
Feature:
-
Low Consumption
|
Model |
Unit |
CPCD120 |
||
|
Vehicle configuration |
HNF-120 |
|||
|
Performance |
Rated load |
|
12 |
|
|
Load center |
|
600 |
||
|
Mast tilt angle (front/rear) |
º |
6/12 |
||
|
Overall dimensions |
Length with fork |
mm |
6055 |
|
|
Width |
mm |
2250 |
||
|
Height |
mm |
3100 |
||
|
Mast lifting height |
mm |
3000 |
||
|
Fork size (L*W*H) |
mm |
1200X180X90 |
||
|
Min. turning radius |
mm |
4450 |
||
|
Max. travel speed (with load) |
Km/h |
23 |
||
|
Lifting speed (with load) |
mm/s |
220 |
||
|
Gradeability (with load) |
% |
20 |
||
|
Weight |
Kg |
18000 |
||
|
Tyre |
Front |
|
4X10.00-20/16PR |
|
|
Rear |
|
2X 10.00-20/16PR |
||
|
Wheel tread |
Front |
mm |
1605 |
|
|
Rear |
mm |
1970 |
||
|
Wheelbase |
mm |
3000 |
||
|
Min. ground clearance |
mm |
350 |
||
|
Engine |
Model |
|
CUNNINS QSC4.5-C130 |
|
|
Rated power/rotate speed |
KW/r.pm |
97/2200 |
||
|
No. of cylinder |
|
4 |
||
