Quick Details
-
Brand Name:
-
Pingte
-
Place of Origin:
-
ZHE
-
Size:
-
2940*100*1360mm
-
Certification:
-
CE, Eec
-
Top Speed (km/h):
-
≤30-40km/h
-
3 speed:
-
20km/30km/40km
-
load capacity:
-
800-1000kgs
-
Net Weight:
-
230kgs
-
Power (watt):
-
60V/1200W(adjustable)
-
Dimension:
-
2940*100*1360mm
-
Transmission mode:
-
Gear
-
Brake type:
-
Front disc + rear drum brake
-
Battery:
-
60V45ah(The advertised price does not include the battery price)
-
Motor Type:
-
series excitation brushless
Quick Details
-
Power:
-
> 1000W
-
Voltage:
-
60V
-
Tire Size:
-
Front: 3.50-12(higher) Rear: 4.00-12(higher)
-
Brand Name:
-
Pingte
-
Place of Origin:
-
ZHE
-
Size:
-
2940*100*1360mm
-
Certification:
-
CE, Eec
-
Top Speed (km/h):
-
≤30-40km/h
-
3 speed:
-
20km/30km/40km
-
load capacity:
-
800-1000kgs
-
Net Weight:
-
230kgs
-
Power (watt):
-
60V/1200W(adjustable)
-
Dimension:
-
2940*100*1360mm
-
Transmission mode:
-
Gear
-
Brake type:
-
Front disc + rear drum brake
-
Battery:
-
60V45ah(The advertised price does not include the battery price)
-
Motor Type:
-
series excitation brushless
Product Details
Product Paramenters
|
Standard Components
|
|
|
|
|||
|
Product Name
|
Tricycles
|
Tires
|
F:3.50--12 R:4.00-12
(adjustable)
|
|||
|
Model Number
|
ET-C01
|
Headlight
|
Round LED Headlight
|
|||
|
Motor Type
|
60V/
1500W
(adjustable)
series excitation brushless
|
Suspension
|
Front Hydraulic Shock Absorption
|
|||
|
Battery
|
Without battery
|
Light
|
LED Headlight, Brake Light and Turning Signal Light
|
|||
|
Dashboard
|
LCD Speed Meter and Power Indicator
|
Carriage
|
1.5*1M
|
|||
|
Break Type
|
Double rear drum brake
|
Color
|
Blue
|
|||
|
OEM
|
Yes
|
MOQ
|
2
|
|||
|
Performance
|
|
|
|
|||
|
Charging time
|
4-8 Hours
|
Loading
|
800-1500 KGS
|
|||
|
Dimension
|
2900*1000*1370mm
|
Climbing ability
|
Up to 30 Degree
|
|||
|
speed
|
40 KM/H
|
Warranty
|
1 Year
(Controller/Battery/Motor)
|
|||
|
Endurance
|
≤120km(adjustable)
|
Start Function
|
Normal Start Funtion
|
|||
|
Components Upgrade
|
|
|
|
|||
|
Battery
|
60v 20ah-52ah(optional)
|
Extra spare parts
|
Intelligent Anti-theft Alarm
|
|||
|
Motor
|
2000W series excitation brushless
|
|
Charger/Front disc break/Rain cover/Front cabin/Stainless steel body/Off-road tyres/1.6*1.1M carriage/1.8*1.1M carriage/Front disc brake/Solar panel/Gear shifting
|
|||
|
Packing
|
|
|
|
|||
|
Gross Weight
|
365KG
|
Packing Size
|
2800*1100*850 mm
SKD: 20' GP 12pcs
40' HQ :35 pcs
CKD: 20' GP :25 pcs
40' HQ :55 pcs |
|||
|
Net Weight
|
365KG
|
Packing Type
|
Wooden box(optional)/SKD/CKD
|
|||
|
Logistic
|
|
|
|
|||
|
Shipping
|
Ocean/Rail Way/Express
|
Loading Port
|
Qingdao Port(CNZP)
|
|||
|
Model
|
Q10
|
|
|
|
Speed/Load
|
Top Speed (km/h)
|
≤40km/h
|
|
|
|
Continued trip mileage
|
≤100
|
|
|
|
load capacity
|
≤1000 kgs
|
|
|
|
Net Weight
|
230kgs
|
|
|
Battery/Motor
|
Battery
|
12v 45ah
|
|
|
|
Battery Quantity
|
5 pcs
|
|
|
|
Charge Voltage
|
220V,50HZ
|
|
|
|
Charging Time
|
6-8 hours
|
|
|
|
Motor Type
|
series excitation brushless
|
|
|
|
Power (watt)
|
60 V 1500W/2000W
|
|
|
Size
|
Front wheel size
|
3.50-12
|
|
|
|
Rear Wheel Size
|
4.00-12
|
|
|
|
Ground Clearance
|
250mm
|
|
|
|
Dimension
|
2860*1200*900mm
|
|
|
Other
|
Transmission mode
|
Gear
|
|
|
|
climbing ability
|
≤30degree
|
|
|
|
Brake type
|
double rear drum brake
|
|
|
|
Container QTY
|
25Set/20'GP, 55Set/40'HQ
|
|
Let us customized products(China Tricycle).
|
Carriage
|
1. 1500*1000mm (normal)
|
|
|
2. 1600*1000mm (custom)
|
|
|
3. 1800*1100mm (custom)
|
|
Motor
|
1. 1200W
|
|
|
2. 1500W
|
|
|
3. 2000W
|
|
Battery
|
1. 20Ah60V
|
|
|
2. 45Ah60V
|
|
Color
|
1. Green
|
|
|
2. blue
|
|
Tyre
|
1. 3.50-12
|
|
|
2. 4.00-12
|
|
|
3. 4.00-14
|
|
Coating
|
1. stoving varnish
|
|
|
2. electrophoresis
|
|
Rear axle
|
1. complete rear axle
|
|
|
2. fission rear axle
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
