Utilize our
AI-ECG analysis system PC software
to save unlimited monitoring records and submit them online
for AI-based ECG interpretation. Benefit from cutting-edge technology that can
identify 17 abnormal ECG
patterns
, providing you with comprehensive insights to Identify potential heart problems including Atrial
Fibrillation, Atrial Flutter and more.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Wellue
-
Model Number:
-
ER1-LW
-
Lead type:
-
Single Lead
-
Power supply:
-
Rechargeable polymer battery; 3.8V DC, 240mAh
-
Battery life:
-
168 hours (fully charged)
-
Charging input:
-
voltage range 4.5 ~ 5.5V DC
-
Charging time:
-
3 hours (to 90% capacity)
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wellue
-
Model Number:
-
ER1-LW
-
Lead type:
-
Single Lead
-
Power supply:
-
Rechargeable polymer battery; 3.8V DC, 240mAh
-
Battery life:
-
168 hours (fully charged)
-
Charging input:
-
voltage range 4.5 ~ 5.5V DC
-
Charging time:
-
3 hours (to 90% capacity)
Product Description
Support intelligent ECG interpretation，Powered by AI-ECG
Manual and Auto Event Trigger
ER1-LW supports
manual marking of abnormal events.
When the user feels uncomfortable, the patient can mark it through the function buttons on the monitor. In addition,
the AI-ECG analysis system software supports automatic event marking of the full electrocardiogram recording, helping health providers to more efficiently analysis cardiac activity and heart health.
Technical Specifications
|
Classification
|
|
|
|
ECG
|
|
|
|
Lead type
|
Single-lead ECG
|
|
|
Lead
|
The waveform is similar to Lead Ⅱ ECG
|
|
|
Input impendence
|
≥10MΩ, 10Hz
|
|
|
Input signal range
|
10mV (peak-to-bottom)
|
|
|
Common mode rejection ratio
|
≥60dB
|
|
|
Frequency response
|
0.67 - 40 Hz
|
|
|
Gain error
|
Maximum error ±10%
|
|
|
Physical
|
|
|
|
Size
|
100×23×8.3 mm
|
|
|
weight
|
<18 g (including battery)
|
|
