Quick Details
-
Power:
-
103kw
-
Dimension(L*W*H):
-
20*6*6m
-
Certification:
-
ce
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Working type:
-
Automatic
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinda
-
Weight (KG):
-
20000 KG
-
Power:
-
103kw
-
Dimension(L*W*H):
-
20*6*6m
-
Certification:
-
ce
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Working type:
-
Automatic
Purpose
This s sand blasting room for vessel&truck surface cleaning is primarily for shot-blasting of big steel structural parts, vessel, truck chassis to remove the rusty spot, rusty layer and scale cinder on steel to obtain a uniform, smooth and glossy metal surface allowing improved coating quality and higher anti-corrosion performance. To ensure the high shot-blasting performance and protect the wall , the grinding-resistant rubber is installed on the room wall .
Working conditions for the shot-blasting room
- 380 V-3- 5 0hz
- 27 m3/min 0.5-0.7MP
Major Technical Parameters
|
No |
item |
specifications |
|
|
1 |
Cleaning effect |
GB8923-88A-B Sa2.5 |
|
|
2 |
Sand blasting room size |
20 000*6000*6000mm (length*width*height) |
|
|
3 |
Truck chassis |
16000*2700*1500mm (length*width*height) |
|
|
|
|
Weight:4500kg |
|
|
4 |
Steel shot blasting machine ( 2 set ) |
model |
KPBSEII1990Z |
|
Shot blasting gun amount |
4 set |
||
|
Working pressure of compressed air |
0.5-0.7MP |
||
|
sand storage |
0.8m 3 |
||
|
Throw the pill quantity |
7200kg /h* 2 |
||
|
abrasive blasting area |
15~20m² /per gun |
||
|
5 |
Elevator |
Elevating capacity :30t/h |
|
|
power :4kw |
|||
|
6 |
Separator |
Separating Capacity :30t/h |
|
|
Power: 3kw |
|||
|
7 |
spiral conveyer |
Conveying capacity :30t/h |
|
|
power: 3 KW *6 |
|||
|
8 |
halogen lamp (C0400Z) |
2 50LUX 400W*10 |
|
|
9 |
Chain trailer |
Capacity: 5000kg |
|
|
Power:4kw |
|||
|
10 |
Belt conveyor |
Capacity:30T |
|
|
Power:4kw |
|||
|
11 |
First pour ing shot qty |
15000kg |
|
|
12 |
Overal room dust collector |
Airflow:55000m 3 /h |
|
|
Power :55kw |
|||
|
1 3
|
Dust collector for |
Air flow:10000 m 3 /h |
|
|
Power :11kw |
|||
|
1 4 |
Overall Noise |
≤85dB |
|
|
1 5 |
Overall power |
About 103 kw (not include a ir compressor ) |
|
Overall air consumption
|
NO |
device name |
qty |
air consumption ( (m 3 /min)) |
Total( (m 3 /min)) |
|
1 |
Sand blaster |
4 |
6 |
24 |
|
2 |
face guard |
4 |
0.1 |
0.4 |
|
3 |
Dust collector |
2 |
1 |
2 |
|
|
total |
|
|
26.4 |
Overall electrical power
|
No |
item |
power (kW) |
|
1 |
Dust collector for overall room |
55 |
|
2 |
Dust collector for separator |
11 |
|
3 |
Elevator |
4 |
|
4 |
Separator |
3 |
|
5 |
Helix conveyer |
3 ×6 |
|
6 |
Working lamp |
400w*10 |
|
7 |
Chain-trailer |
4 |
|
8 |
Belt conveyor |
4 |
|
9 |
a ir compressor |
Equipped by user |
|
10 |
Total power |
103 |
