Quick Details
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, LAS, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Dimension(L*W*H):
-
950*630*490mm
-
Weight (KG):
-
35 KG
-
Product name:
-
320 C02 Laser Engraving Cutting Machine
-
Laser head:
-
Red Point
-
Working table:
-
Honeycomb Working Table
-
Support material:
-
MDF Acrylic Glass Wood Plastic
-
Support software:
-
Coreldraw Output Directly
-
Cutting thickness:
-
0-20mm(depends
-
Brand Name:
-
Flash Laser
-
Laser:
-
320 Laser Enrgraving Cutting Machine
-
Laser tube:
-
Sealed CO2 Glass Tube
-
Control system:
-
Ruida Control System
Quick Details
-
Engraving Area:
-
400mm*300mm, 300mm*200mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-400mm/s
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, LAS, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Dimension(L*W*H):
-
950*630*490mm
-
Weight (KG):
-
35 KG
-
Product name:
-
320 C02 Laser Engraving Cutting Machine
-
Laser head:
-
Red Point
-
Working table:
-
Honeycomb Working Table
-
Support material:
-
MDF Acrylic Glass Wood Plastic
-
Support software:
-
Coreldraw Output Directly
-
Cutting thickness:
-
0-20mm(depends
-
Brand Name:
-
Flash Laser
-
Laser:
-
320 Laser Enrgraving Cutting Machine
-
Laser tube:
-
Sealed CO2 Glass Tube
-
Control system:
-
Ruida Control System
Small 40W Mini Laser Cutting Machine 320 K40 Rubber Stamp Portrait
Badges Chest Cards 3020 50W laser co2 engraving machine
40W Mini Laser Engrave And Cutting Machine 320 K40 Small Laser Cutting Machine 3020 50W
Small K40 laser engraving mobile phone cutting film machine
cutter acrylic laser co2 engraving machine 320 K40 50W Technical Parameters
| Laser Power | 40W/50W |
| Supply Voltage | 110/220V±10% ,50/60Hz |
| Working Area Size | 400*300mm |
| Working table | Aluminum plate |
| Up and down size | 80mm(optional) |
| Table control mode | Manual |
| Max engraving Speed | 500mm/s |
| Max cutting speed | 100mm/s |
| Locating Precision | <0.01mm |
| Min shaping character | Character 2x2mm ,Letter 1x1mm |
| Resolution | 0.0125mm |
| Cutting thickness | 0-15mm |
| Control Configuration | MINI DSP |
| Data transfer Interface | USB |
| System Environment | WINDOWS XP/Win7/8 |
| Graphic file format | BMP,PLT,AI,CDR,DXF |
| 256 Color separation output | NO |
| 360 degree slope engraving | Support |
| Off line working | NO |
| Cooling Way | Water Cooling |
| Operating temperature | 5°C -45°C |
| Water protecting sensor and alarm | Yes |
| Net Weight | 60KG |
| Machine dimension | 950*600*350mm |
| Option | Up&Downtable,Honeycomb Worktable,Rotary Device,Red Dot Position System,Auto-focus Device |
| Working video | https://www.youtube.com/watch?v=_TRbydJJC-0 |
| https://www.youtube.com/watch?v=VTB05Yh_w1o | |
| https://www.youtube.com/watch?v=4H8rGaayApQ | |
| https://www.youtube.com/watch?v=-M-PPho50Bo |
Honey comb platform or knife blade platform
Laser head industrial laser head
Offline control panel
Belt(Taiwan imported wearing resisting)
Stepper Motor
Rail (Taiwan Liner guide Rail)
Ruida Offline control board
Reci laser tube
Small K40 laser engraving mobile phone cutting film machine cutter acrylic laser co2 engraving machine 320 K40 50W
Applicable Materials : Acrylic/ Plexiglas/ double color board/ ABS board/PVC board/
bamboo/ MDF/ wood/ paper / leather/ fabric/ wool/ rubber/ resin etc.
Applicable Industries :Advertisement( marks/ signs/ billboards/plates) bamboo & wood product
/ art craft work/ ornament/ paper-cutting /cloth/ fabric/ hang bag/ glove/ garment/ leather/
embroidery/ shoemaking/ toy/ crystal/ packing & printing/ panel/ mould/
decoration/upholster and other related industries.
Small K40 laser engraving mobile phone cutting film machine
cutter acrylic laser co2 engraving machine 320 K40 50W Part Details
2022 Mini CO2 Laser Engraving Machine 320 Laser Carving Machine K40 Laser Cutting Plywood Plastic
Samples pics of K40 laser engraving machine mobile phone cutting film DIY
calligraphy and painting rubber seal engraving machine
Small K40 laser engraving mobile phone cutting film machine cutter acrylic laser co2 engraving machine 320 K40 50W
Applicable materials
wood,MDF,acrylic,plastic,plexiglass,crystal,rubber,fabric,paper and other non-metal materials.
Cheapest 40W Mini Laser Engrave And Cutting Machine 320 K40 Small Laser Cutting Machine 3020 50W
2022 Mini CO2 Laser Engraving Machine 320 Laser Carving Machine K40 Laser Cutting Plywood Plastic
We deliver the mini machines of small number and samples by express such as DHL,TNT,UPS,FedEx ,etc.
For large-scale engraving cutting machines,we ship the goods by sea .
Small K40 laser engraving machine mobile phone cutting film DIY calligraphy painting rubber seal engraving
1.we are directly maufacturer of laser cutting machine ,laser engraving machine,
cnc router with rich experience in liaocheng city, shandong province, china.
2.free make sample. free training for how to operate the machine.
3.good quality good price.no middle businessman make the profit. directly price to supply to client.
4.CE ISO certificate.
